Description
Kenwood eXcelon XR601-1
The Kenwood XR601-1 is a compact mono Class D car amplifier designed specifically for powering subwoofers with strong and clean bass output. It delivers 400W RMS at 4 ohms and up to 600W RMS at 2 ohms, making it ideal for medium to high-power subwoofer setups. Its advanced circuit design reduces noise and distortion, ensuring clear low-frequency performance. The amplifier features a variable low-pass filter, bass boost control, and a wired remote level control for easy bass adjustment from the front seat. With its ultra-slim design, it can be installed easily in tight spaces without compromising performance.
Specifications
| Specification | Details |
|---|---|
| Model | XR601-1 |
| CTA-2006-D Value | Maximum Dynamic Power: 500W at 4Ω and ≤ 10% THD + N |
| Continuous Power Output | 400W at 4Ω and ≤ 1% THD + N |
| Signal to Noise (1W reference) | 78 dBA |
| Max Power Output | – |
| Rated Power Output (14.4V) | 400W x 1 (4Ω) (20Hz–200Hz, 1.0% THD) |
| 600W x 1 (2Ω) (100Hz, 1.0% THD) | |
| Frequency Response | 20–200 Hz (±1 dB) |
| Input Sensitivity | 0.2V – 5.0V (Min–Max) |
| Input Impedance | 10 kΩ |
| Signal to Noise Ratio | 100 dB |
| Low Pass Filter Frequency | 50 Hz – 200 Hz (variable, -24 dB/oct.) |
| High Pass Filter Frequency | – |
| Dimensions (W × H × D) | 220 × 35 × 169 mm (8-11/16 × 1-3/8 × 6-5/8 in) |
