Kenwood eXcelon XR-W1004(4Ω)
The Kenwood XR-W1004 (4Ω) is a high-quality 10-inch eXcelon Reference series car subwoofer designed for powerful, tight, and accurate bass performance. It features an oversized polypropylene cone, reinforced rubber surround, and a strong magnetic circuit that delivers deep low-frequency response with low distortion. With 300W RMS and up to 1300W peak power handling, it is ideal for small sealed enclosures where space is limited but strong bass output is required. Its dual ventilation system improves heat control and long-term durability, making it suitable for daily driving and high-quality car audio setups.
Specifications
| Category | Specification | Details |
|---|---|---|
| Model Name | XR-W1004 | – |
| Woofer Size | 25 cm (Over sized 10″) | – |
| Diaphragm | PP Cone | Gray |
| Surround | Rubber | Black |
| Basket | Steel | Black |
| Magnet | Ferrite | φ140 × t16 × 2 pcs |
| Dimensions (Woofer Unit) | Width | 10-13/16 in |
| Height | 10-13/16 in | |
| Cutout Diameter | 9-1/8 in | |
| Depth | 5-5/8 in | |
| Mounting Depth | 4-13/16 in | |
| Weight | Woofer (each) | 11.5 lb (5.2 kg) |
| Gross Weight | 13.5 lb (6.1 kg) | |
| Impedance | Nominal | 4 Ω |
| Power Handling | Peak Power | 1300 W |
| RMS Power (CEA spec) | 300 W | |
| Sensitivity | 82 dB (1W/1m) | – |
| Frequency Response | 31 Hz – 300 Hz | – |
| Accessories | Screw Set | φ4 × 35 mm, 8 pcs |
| Cushion | 1 pc | |
| Warranty Card | 1 pc | |
| Special Features | Ventilation | Dual ventilation system |
| Cone | Oversized cone | |
| Damper | Stress-free damper | |
| Terminal | 8 AWG push terminal | |
| Magnet Cover | Rubber |
