Description
Memphis MM900.6V
The MM900.6V is a 6-channel Class-D marine amplifier designed for boats and powersports vehicles. It features IPX5 water resistance, sealed top-mounted controls, and sealed signal connectors for reliable performance in wet environments. The amplifier includes removable power terminals for easier installation, protection circuitry against overload, short-circuit, thermal, and reverse polarity, fully variable crossovers, a 12 dB bass boost centered at 45 Hz, a 24 dB infrasonic filter to protect subwoofers, and a remote bass knob for convenient control.
Features
| Feature | Details |
|---|---|
| Water Resistance | IPX5 rated |
| Power Terminal | Removable |
| Signal Connectors | Sealed removable |
| Controls | Sealed top mount |
| Heat Sink | Extruded aluminum |
| Turn-On | Signal sensing auto turn on |
| Crossovers | 12dB/octave Butterworth; fully variable |
| Input Select | Input select switch |
| LED | LED light strip |
| Remote | Bass knob (MM900.6V & MM600.2V) |
| Protection | Overload, short circuit, thermal & reverse polarity |
| Bass Boost | Variable, 0–12dB centered at 45Hz |
| Infrasonic Filter | 24dB |
Specifications
| Specification | Details |
|---|---|
| RMS Power 4Ω | 70 × 4 + 200 × 2 W |
| RMS Power 2Ω | 90 × 4 + 300 × 2 W |
| RMS Power 1Ω | N/A |
| Bridged/Mono Power 4Ω | 200 × 2 + 600 × 1 W |
| THD% 4Ω | <1% |
| Frequency Response | 10 Hz – 36 kHz |
| Dimensions (L × W × H) | 13.1 × 7.3 × 2 in |
| Input Range | 200 mV – 20 V |
| Amp Kit | 4GKIT |
