Description
Kenwood KFC-1366S
The Kenwood KFC-1366S is a 5.25-inch (13 cm) 2-way coaxial car speaker system designed for factory speaker replacement upgrades. It delivers improved clarity, balanced mids, and clean high frequencies, making it a solid upgrade over standard OEM car speakers. Ideal for compact factory speaker locations where space is limited but better sound quality is needed.
Specification
| Category | Parameter | Value |
|---|---|---|
| Electrical | Peak Input Power | 260 W |
| Electrical | Rated Input Power | 30 W |
| Electrical | Impedance | 4 ohms |
| Woofer | Woofer Size | 5-1/4 inch |
| Woofer | Woofer Material | PP Cone |
| Tweeter | Tweeter Type | 1 inch Balanced Dome |
| Specifications | Sensitivity | 89 dB / W / m |
| Specifications | Frequency Response | 45 Hz – 22 kHz |
| Dimension | Cutout Diameter | 4-7/16 inch |
| Dimension | Mounting Depth | 1-3/4 inch |
| Weight | Gross Weight | 2.2 lbs |
| Weight | Woofer Magnet Weight | 0.35 lbs |
| Category | Parameter | Metric | Imperial / Details |
|---|---|---|---|
| Model | Model | KFC-1366S | — |
| Electrical | Impedance | 4 Ω | — |
| Electrical | Peak Power | 260 W | — |
| Electrical | Rated Power | 30 W | — |
| Electrical | Sensitivity | 89 dB / W @ 1m | — |
| Electrical | Frequency Response | 45 Hz – 22 kHz | — |
| Woofer | Size | 130 mm | 5.25 in |
| Woofer | Diaphragm | PP Cone | — |
| Woofer | Surround | Cloth | — |
| Woofer | Basket | Steel (Black) | — |
| Woofer | Magnet | Ferrite (φ70×t10) | — |
| Tweeter | Size | 25 mm | 1 in |
| Tweeter | Diaphragm | PEI Balanced Dome | — |
| Dimension | Width (with grille) | 157.0 mm | 6-3/16 in |
| Dimension | Width (without grille) | 130.0 mm | 5-1/4 in |
| Dimension | Height (with grille) | 157.0 mm | 6-3/16 in |
| Dimension | Height (without grille) | 130.0 mm | 5-1/4 in |
| Dimension | Cutout Diameter | 112.0 mm | 4-7/16 in |
| Dimension | Depth (with grille) | 66.5 mm | 2-5/8 in |
| Dimension | Depth (without grille) | 50.8 mm | 2 in |
| Dimension | Mounting Depth | 43.5 mm | 1-3/4 in |
| Weight | With Grille (per pc) | 475 g | 1.0 lbs |
| Weight | Without Grille (per pc) | 423 g | 0.9 lbs |
| Weight | Gross Weight | 1013 g | 2.2 lbs |
| Weight | Magnet Weight | 160 g | 5.6 oz |
| Accessory | Grille | 2 pcs | — |
| Accessory | Screw Set | φ4×25 (8 pcs) | Tapping screws |
| Accessory | Speed Nut | 8 pcs | — |
| Accessory | Speaker Cord | 0.3 m × 2 pcs | — |
| Accessory | Warranty Card | 1 pc | — |
| Packaging | Carton Size | 312 × 180 × 86 mm | 4-color box |
