Description
Pioneer SPH‑10BT
The Pioneer SPH‑10BT is a single‑DIN digital‑media receiver designed for drivers who want modern smartphone integration without a built‑in display, as the unit uses your smartphone screen via a built‑in cradle. It includes built‑in Bluetooth® for hands‑free calls and music streaming, a USB port for playback of audio files (including FLAC) and quick‑charging a connected device, and full control using the Pioneer Smart Sync® app which enables navigation‑app access, voice‑control via Amazon Alexa and a 31‑band graphic equaliser when paired with the app.
Specifications
PRODUCT PERFORMANCE
| Feature | Specification |
|---|---|
| Continuous Power Output | 22 W x 4-Channel |
| Load Impedance Allowance | 4 Ohm (4 Ohm to 8 Ohm Allowable) |
| Max Power Output | 50 W x 4-ch 4 ohm, 50 W x 2-ch 4 ohm, 70 W x 1-ch (subwoofer) 2 Ohm |
| RCA Preamp Outputs | 4-ch |
| RCA Preout Voltage | 2V |
| RMS Power Output (CTA-2006) | 14 W RMS x 4-ch 4 ohm |
GENERAL
| Feature | Specification |
|---|---|
| Detachable Face Security | Detachable |
| Multi-Language Display | English, French, Spanish |
| Music Browser | USB, With Smart Sync App |
| Parking Sensor Input | Yes (Optional with ND-PS1) |
| Remote Control | Optional |
| Smartphone Cradle | Yes |
| Steering Wheel Control Ready | Yes (Adapter Sold Separately) |
DISPLAY
| Feature | Specification |
|---|---|
| Back Light | LED |
| Brightness Control | Yes |
| Color Customization | 210000 Colors with Pioneer Smart Sync, 12 Preset Colors without Pioneer Smart Sync |
| Device Display | VA LCD (1-Line) |
| Device (Non-DIN/Modular Unit) | 1-DIN |
| Dimmer | Automatic with vehicle illumination, Timer Controlled, Manual |
BLUETOOTH
| Feature | Specification |
|---|---|
| Advanced Audio Distribution Profile (A2DP) | Yes |
| AVRCP | 1.6 |
| Built-in Bluetooth® | Yes |
| Hands-Free | Yes |
| Microphone Included | Included |
| Phone Registration | 5-phone |
| Secure Simple Pairing (SSP) | Yes |
| Serial Port Profile (SPP) | Yes |
| Sound Retriever Air | Mode 1/Mode 2/Off |
TUNER
| Feature | Specification |
|---|---|
| Best Station Memory | Yes |
| Local Seek Tuning | Yes |
| Presets | 18 FM, 6 AM |
| RDS | Yes |
INTEGRATION
| Feature | Specification |
|---|---|
| Amazon Alexa | Paired with Pioneer Smart Sync |
| Mobile Operating System | Android, Apple iOS |
| Pandora® | Source with Pioneer Smart Sync |
| Pioneer App Compatibility | Pioneer Smart Sync Android, Pioneer Smart Sync iPhone, Apple Maps with Pioneer Smart Sync, Google Maps with Pioneer Smart Sync, WAZE with Pioneer Smart Sync |
| Spotify | Source with Pioneer Smart Sync |
| Voice Control | Yes |
DIGITAL MEDIA PLAYBACK
| Feature | Specification |
|---|---|
| Audio Playback via USB | MP3, WMA, AAC, FLAC (Hi-Res), WAV (Hi-Res) |
AUDIO
| Feature | Specification |
|---|---|
| Advanced Sound Retriever | Mode-1/Mode-2/Off |
| Balance | Yes |
| Built-in Amplifier | MOSFET 50 W x 4 |
| Crossover Standard Mode | HPF/LPF |
| Customizable Graphic Equalizer | 13 Band, 31 Band with Pioneer Smart Sync app |
| DA Converter | 24 Bit |
| Digital Signal Processor | Built In |
| Dynamic Bass Enhancer | Off/Low/High |
| Easy EQ (EEQ) Preset Equalizer | Yes |
| Listening Position Selector | With Pioneer Smart Sync |
| Loudness | High/Mid/Low/Off |
| Source Level Adjuster | Yes |
| Speaker Output | 4-ch |
| Spectrum Analyzer | True |
| Subwoofer Control | Yes |
| Time Alignment | Manual, With Pioneer Smart Sync |
EXPANDABILITY
| Feature | Specification |
|---|---|
| Firmware Upgradability | Yes |
| USB | Front Type-A (5V, 1-1/2 A) |
| USB Direct Control for iPhone® | 5s and newer |
About The Product
The SPH-10BT is a digital media receiver designed to enhance the smartphone lifestyle. Mount your smartphone in the built-in cradle and connect via Pioneer Smart Sync to access navigation, music, messages, and other apps. The receiver has a built-in amplifier with two RCA pre-outs and a 13-band customizable graphic equalizer (expanding to 31 bands when using Pioneer Smart Sync). Additional features include Bluetooth®, USB direct control for iPhone®, and Amazon Alexa integration via the Pioneer Smart Sync app.
Pioneer Smart Sync
A versatile app for iOS and Android that links your smartphone to the receiver via Bluetooth® or USB. Access maps, messages, music, and even OBDII data (with optional module). Alexa is built-in, allowing voice commands to play music, check the weather, control smart home devices, and more. Smart Sync also serves as a wireless remote to tune sound and save settings directly on your smartphone.
Smartphone Control
Directly access and control music and supported apps from your smartphone, with intuitive search by artist, album, or song.
Bluetooth
Make hands-free phone calls and stream audio with crystal-clear sound via the included external microphone.
Siri® Eyes Free
Siri listens through the receiver’s microphone and responds through the vehicle speakers for safer, hands-free operation.
Wired Remote Input
Allows optional connection to a third-party interface for maintaining steering wheel control functions.
Pioneer Advanced Sound Retriever (ASR)
Enhances detail and warmth in compressed audio files by counteracting compression effects for more natural sound.
Audio Equalizer
13-band EQ with multiple presets lets you adjust audio to match your car’s acoustics and speaker setup.
Time Alignment
Adjust delay and synchronization for each speaker to correct phase mismatches based on listening position.
MIXTRAX
Creates continuous DJ-style mixes with transitions and effects from connected iPhone, iPod, USB, or select Android devices. Club-style lighting pulses to the beat, with multiple patterns available via sound pressure or low-pass synchronization modes.
