DS18 EXL-SQ6.9
The EXL-SQ6.9 is a 6×9‑inch 3‑way coaxial car audio speaker pair designed to deliver full-range sound with deep lows, clear mids, and crisp highs, making it an ideal upgrade over factory-installed speakers. Each speaker features a 4 Ω nominal impedance with 65 W RMS (195 W peak) power handling, ensuring efficient performance with head units and aftermarket amplifiers. With a frequency response ranging from 35 Hz to 20 kHz and 87 dB sensitivity, these speakers produce detailed, dynamic audio with excellent volume and clarity. The design includes treated paper woofers with rubber surrounds and dual Mylar dome tweeters for precise sound reproduction across the full spectrum. Built with rugged steel baskets and included protective grills, the EXL-SQ6.9 is perfect for car doors, rear decks, or custom installations where reliable, high-quality sound is required.
Specifications
| Category | Specification |
|---|---|
| SKU | EXL-SQ6.9 |
| Speaker Type | 2-Way Coaxial |
| Nominal Size | 6×9″ |
| Voice Coil | BASV 1.14″ |
| RMS Power | 160 W |
| MAX Power | 560 W |
| Nominal Impedance | 3 Ω |
| Sensitivity | 90 dB / 1W / 1m |
| Frequency Response | 55 Hz – 22 kHz |
Tweeter
| Parameter | Specification |
|---|---|
| Diameter | 1.14″ |
| Material | PEI Dome with Neodymium Magnet |
Woofer
| Parameter | Specification |
|---|---|
| Cone Material | Glass Fiber |
| Surround Material | Rubber Edge |
| Magnet Material | Strontium |
| Magnet Weight | 19.8 oz |
Product Overview
Glass Fiber 6×9″ 2-Way Coaxial Car Speaker 560 Watts 3-Ohm
Instantly increase the sound quality in your car and get EXTREMELY LOUD using DS18’s EXL-SQ6.9!
The 2-way design of the EXL-SQ6.9 equips it with both a woofer and a tweeter working harmoniously to produce a full and dynamic sound. These speakers are capable of reproducing both high and low frequencies with remarkable accuracy.
The EXL-SQ6.9 has a 2-way design with a 3-ohm impedance, making these speakers extremely easy to incorporate into any high-powered audio system.
The glass fiber cone provides stiffness, ensures accurate sound reproduction, and minimizes distortion. It’s lightweight design enables faster and more responsive changes to the signal, while also maximizing energy efficiency.
Every component, from the advanced PEI dome tweeter to the neodymium magnets, and black glass fiber cone has been carefully chosen and tuned to deliver the best possible audio performance. This attention to detail ensures that every detail of your music is reproduced with incredible accuracy.
