Description
DS18 SXE-2000.4D/RD
Power Specifications
| Specification | Value |
|---|---|
| Total Peak Power | 2000 W |
| RMS Power @ 4 Ohm | 4 × 100 W |
| RMS Power @ 2 Ohm | 4 × 160 W |
| RMS Power @ 1 Ohm | N/A |
| RMS Power @ 4 Ohm Bridge | 2 × 320 W |
Audio
| Specification | Value |
|---|---|
| Frequency Response | 10 Hz – 20 kHz |
| Signal-to-Noise Ratio | 90 dB |
| Efficiency @ 4 Ohm | 90% |
| Damping Factor | 200 |
| Input Impedance | 20 kΩ |
| Channel Separation | 60 dB |
| Total Harmonic Distortion (THD) | 0.10% |
| Low Level Input Range | 200 mV – 5 V |
| High Level Input | No |
| Selectable Crossover | HPF / FULL / LPF |
| Crossover Filter Range | 40 Hz – 2 kHz |
| Bass Boost Range | No |
| Bass Boost Frequency | No |
| Infrasonic Filter | No |
| Phase Selector | No |
Features
| Specification | Value |
|---|---|
| Amplifier Class | Digital (D) |
| Amplifier Type | Stereo Full Range |
| Number of Channels | 4 |
| Minimum Impedance | 2 Ohm Stereo / 4 Ohm Bridge |
| LED Indicator | Power / Protect / Clip |
| Power Input Terminal Size | 4 GA |
| Fuse Size | 1 × 40 A |
| Remote Level Control | No |
| Cooling Fan | No |
| Voltmeter | No |
| Thermal Protection | Yes |
| Overload Protection | Yes |
| DC Output Protection | Yes |
| Short Circuit Output Protection | Yes |
| Voltage Input Protection | Yes (16.5 V) |
| Clipping Protection | Yes |
| Body Color / Finish | Red / Black Brushed Aluminum |
Measurements
| Specification | Value |
|---|---|
| Overall Length | 6.4″ / 164.3 mm |
| Overall Width | 5.5″ / 140 mm |
| Overall Height | 1.8″ / 48 mm |
| Heatsink Length | 5″ / 127 mm |
Extra Features
| Specification | Value |
|---|---|
| Compact Size for Easy Installation | Yes |
| Stable/Reliable Two or Four Layer PCB Design | Yes |
| Surface Mount Component Technology | Yes |
| Quality Control Verification using Audio Precision Instruments | Yes |
| Remote Level Control with Clip Indicator | No |
Product Overview
DS18’s SXE Amplifier Series was designed for enthusiasts looking for an extreme increase to the quality of audio reproduced by their vehicle. With the SXE-2000.4D at the helm, your vehicle’s speakers will unleash their true potential, effortlessly detailing the best parts of your favorite tracks.
The SXE-2000.4D offers you the ability to shape your systems audio to match your personal preferences. Its selectable crossover, and multi-channel amplifier design allows you to fine-tune your audio, ensuring every beat, melody, and lyric is reproduced with astonishing accuracy. The compact size of the SXE-2000.4D enables easy installation anywhere in your vehicle, making it a versatile companion for your custom audio setup. Immerse yourself in a customized soundstage that complements your unique style.
Thanks to its Class D circuit design the SXE-2000.4D seamlessly integrates into any vehicle’s custom build, without compromising on its power. Prepare to be blown away by the SXE-2000.4D’s staggering performance, delivering 320W x 2 CH bridged at 4-ohms, 160W x 4 CH at 2-ohms, and 100W x 4 CH at 4-ohms. These power settings are guaranteed to supercharge any custom build.
The SXE-2000.4D also comes equipped with various forms of electronic protection, including thermal protection that shields against overheating, over-load protection, and short circuit output protection. Additionally, the 80℃ thermal protection ensures the amplifier operates optimally, even in demanding conditions. DS18 has thought of everything to guarantee a long-lasting and exceptional audio experience.
