Description
DS18 INF-C1.25A
The DS18 INF‑C1.25A is a portable automatic smart battery charger & maintainer designed to keep 6 V and 12 V vehicle batteries healthy and fully charged. It delivers a 1.25 A output and works with most common battery types including lead‑acid, wet cell, gel, and AGM batteries, making it versatile for cars, motorcycles, marine vehicles, powersports, and audio systems. The built‑in safety protections — including thermal, reverse‑polarity, overcurrent, and overcharge safeguards — help ensure safe charging, while the IP60 dust‑tight housing and simple clamp connections make it durable and easy to use. This charger supports battery capacities from 2 Ah up to 60 Ah, providing efficient maintenance and preventing battery drain during long periods of inactivity.
Specifications
| Category | Specification |
|---|---|
| SKU | INF-C1.25A |
| Charger Type | Maintainer |
| Maximum Output Current (Charging) | 1.25 A |
| Maximum Input Current | Variable up to 30 W (0.27 A) |
| Battery Type Compatibility | Lead-Acid, Wet, Gel, AGM |
| Battery Voltage Compatibility | 6 / 12 V |
| Battery Capacity Compatibility | 2–60 Ah |
| AC Input | 110–120 VAC / 50–60 Hz |
| 6V DC Output Current | 1.25 A |
| 12V DC Output Current | 1.25 A |
| 24V DC Output Current | N/A |
| Minimum Start Voltage | >3 V |
| Housing Protection Rate | IP60 |
| Operating Temperature | 0°C to +40°C |
| Efficiency | Approx. 85% |
Features
| Feature | Yes / No |
|---|---|
| Clamps Type | Battery Clamp |
| Quick Connector | No |
| Function Display Type | LED |
| Voltmeter | No |
| Ammeter | No |
| Boost Mode | No |
| Power Supply Mode | No |
| Low Temperature Charging Mode | No |
| High Temperature Charging Mode | No |
| Battery Repair Mode | No |
| Thermal Protection | Yes |
| Reverse Connection Protection | Yes |
| Overcurrent / Overcharge Protection | Yes |
| Faulty Battery Indicator | Yes |
| Faulty Connection Indicator | Yes |
Product Overview
6V/12V Portable Automatic Smart Battery Charger & Maintainer
With DS18’s INF-C1.25A, it’s easy to maintain and charge your battery to ensure it will operate at it’s MAX, delivering uninterrupted power to your sound system and elevating your experience to new heights.
Equipped with advanced charging and maintaining capabilities, the INF-C1.25A is designed to power a wide range of battery types; including Lead-Acid, Wet, Gel, and AGM. No matter the size and type of your battery, the INF-C1.25A effortlessly delivers a maximum output current of 1.25A, ensuring an efficient charging process. With voltage compatibilities for 6V and 12V systems, the INF-C1.25A is the most versatile charger available today.
The INF-C1.25A is equipped with a range of essential safety features, including thermal protection to prevent overheating, reverse connection protection to safeguard against accidental mistakes, and overcurrent/overcharge protection to maintain a healthy battery life. The INF-C1.25A also has an impressive IP60 protection rating. This means it is dust-tight, ensuring the internal components are shielded from any potential damage. This charger is also temperature tested and operates flawlessly in temperatures ranging from 0°C to +40°C.
Intelligently designed to handle battery capacities ranging from 2Ah to an impressive 60Ah. Your battery’s size won’t matter, the INF-C1.25A provides the perfect charging and maintaining solution for all setups. DS18’s INF-C1.25A is an essential companion for every audio enthusiast.
*DOES NOT SUPPORT LITHIUM BATTERIES – SEARCH DS18’s INF-C SERIES FOR OPTIONS WITH LITHIUM CAPABILITIES*
