Description
Autotek MM3020.1D
Details & Specs
| Category | Specification |
|---|---|
| Type | Amplifier |
| Brand | Autotek |
| Series | Compact MEAN MACHINE |
| Category | Mobile |
| Condition | New |
| Color | Black |
| Warranty | 1 Year |
| Compatible Vehicles | Universal |
| Amp Class | Class D |
| Total Channels | 1 |
| Max Power | 3000 Watts |
| Power @ 1 Ohm | 1 × 3000 W |
| Power @ 2 Ohms | 1 × 1500 W |
| Power @ 4 Ohms | 1 × 750 W |
| Crossover | Variable Electronic (12dB per Octave) |
| Low Pass Crossover | 40Hz – 300Hz |
| Tone Control / EQ | Built-in Bass Control |
| Bass Boost | 0 – 12 dB |
| Subsonic Filter | 10Hz – 40Hz |
| Variable Voltage | 0.2 – 6V |
| Frequency Response | 10Hz – 500Hz |
| Total Harmonic Distortion (THD) | < 0.1% |
| Speaker Level Inputs | Yes |
| Pre-amp Outputs | RCA |
| Power Terminal | 4 AWG |
| Speaker Terminal | 12 AWG |
| Fusing | External 125A |
Features & Benefits
| Feature | Description |
|---|---|
| Low Noise Preamplifier Circuit | Ensures low voltage signal input with minimal distortion during amplification |
| RCA Inputs | Provides high-quality audio connection via RCA inputs and outputs |
| Operation Mode | Mono only |
| Crossover Type | Onboard electronic crossover |
| Electronic Equalizer | Built-in EQ for tuning frequencies for speakers and subwoofers |
| Class / Topology | Efficient Class D design with compact size and high power output |
| Output Device Technology | ROAD WORTHY™ TCID and PRO-FI™ High Speed MOSFETS for high power and low distortion |
| Heat Sink | Heavy-duty aluminum alloy heatsink with illuminated logo |
| Power Supply | PWM (Pulse Width Modulated) power supply for efficient high power output |
| Output Connections | Nickel-plated brass terminals with hex screws for durability and secure fit |
| Connection Type | Angled Allen key connectors for easy and secure installation |
| Full-Range RCA Outputs | Enables signal pass-through to additional amplifiers, reducing wiring and noise |
| LED Protection Diagnostics | Built-in indicators for overload and speaker short protection monitoring |
| Bass Remote Included | Wired remote control for adjusting bass levels from anywhere in the vehicle |
Overview
Autotek MEAN MACHINE compact series of car audio amplifiers bring extreme power with PRO-FI™ High Speed MOSFETS and high sound quality with minimum distortion levels. The MM-3025.1D features 3000 watts of power in a 1 Ohm stable monoblock amplifier designed to power a mono subwoofer system. The Class D technology provides extreme power in a smaller footprint.
