Autotek MM-1525.2D
Details & Specs
| Category | Specification |
|---|---|
| Type | Amplifier |
| Brand | Autotek |
| Series | Compact MEAN MACHINE |
| Category | Mobile |
| Condition | New |
| Color | Black |
| Warranty | 1 Year |
| Compatible Vehicles | Universal |
| Amp Class | Class D |
| Total Channels | 2 |
| Max Power | 1500 watts |
| Power @ 2 Ohms | 2 x 750 watts |
| Power @ 4 Ohms | 2 x 375 watts |
| Mono Bridged @ 4 Ohms | 1 x 1500 watts |
| Crossover | Variable Electronic 12dB Per Octave |
| High Pass Crossover | 40Hz – 400Hz (12dB/Octave) |
| Low Pass Crossover | 40Hz – 400Hz (12dB/Octave) |
| Tone Control / EQ | Built-in Bass Control |
| Variable Voltage | 0.2 – 6V |
| Frequency Response | 10Hz – 22kHz |
| Total Harmonic Distortion (THD) | < 0.05% |
| Audio Inputs | RCA |
| Pre-amp Outputs | RCA |
| Power Terminal (12V/GND) | 4 AWG |
| Speaker Terminal Wire Gauge | 12 AWG |
| Fusing | External 50A |
Features & Benefits
| Feature | Description |
|---|---|
| Low Noise Preamplifier Circuit | Low voltage signal circuit ensures minimal distortion during amplification |
| RCA Inputs | High-quality RCA inputs and outputs for clean, low-noise signal transfer |
| Operation Mode | Two-channel, full-range, bridgeable (stereo or mono bridged operation) |
| Crossover Type | Onboard electronic crossover for frequency control |
| Electronic Equalizer | Built-in EQ with crossover for tuning speakers and subwoofers |
| Class / Topology | Efficient Class D design with compact footprint and high power output |
| Output Device Technology | ROAD WORTHY™ TCID and PRO-FI™ High Speed MOSFETs for strong output and low distortion |
| Heat Sink | Heavy-duty aluminum alloy heatsink with illuminated logo display |
| Power Supply | High-energy PWM (Pulse Width Modulated) system for efficient power delivery |
| Output Connections | Nickel-plated brass terminals with hex set screws for secure and corrosion-resistant connection |
| Connection Type | Angled Allen key connectors for quick and secure installation |
| Full-Range RCA Outputs | Signal pass-through allows linking multiple amplifiers with reduced noise and wiring complexity |
| LED Protection System | LED indicators for overload and speaker short-circuit protection |
Overview
Autotek MEAN MACHINE compact series of car audio amplifiers bring extreme power with PRO-FI™ High Speed MOSFETS and high sound quality with minimum distortion levels. The MM-1525.2D features 1500 watts of power in a bridgeable 2 channel Class D amplifier. The Class D technology provides extreme power in a smaller footprint. The amplifier can be run from the “output” RCA connections which minimize the need for additional cables running the length of the vehicle.
