Pioneer TS‑X150

Name: Pioneer TS‑X150
SKU: TS-X150
Availability: InStock

SKU: TS-X150

$103.90

In stock

100 in stock

Categories: Speaker Pods, Speaker with Pods, Speakers Tags: IMPP cone shelf speaker, Pioneer TS‑X150, TS‑X150

Description

3-way Surface Mount

Features

Frequency response:
75 Hz - 20,000 Hz
Impedance:
4 Ω
Maximum input power:
60 W

Description

Description

Pioneer TS‑X150

The Pioneer TS‑X150 is a 13 cm (≈ 5¼″) 3‑way surface‑mount speaker designed for shelf or custom‑mount installations rather than standard door mounts. It features an IMPP™ composite‑cone woofer, horn‑midrange and horn‑tweeter for a fuller sound range. The speaker has a nominal power rating of 20 W, maximum input power of 60 W, sensitivity of 89 dB (1 W/1 m), impedance of 4 Ω, and a frequency response spanning approximately 75 Hz to 20 kHz

Specifications

Feature	Specification
Frequency Response	75 Hz – 20,000 Hz
Impedance	4 Ω
Maximum Input Power	60 W
Nominal Input Power	20 W
Sensitivity	89 dB
Series	Surface Mount
Diameter Size	13 cm
Dimensions (W × H × D)	300 mm × 111 mm × 166 mm
Magnets	Ferrite
Woofer Material	IMPP™
Speaker Grill	Included
Weight	1.06 kg

Reviews

There are no reviews yet.

Be the first to review “Pioneer TS‑X150”

Questions and Answers

Q1: What size is the TS‑X150?

A1: It is approximately 13 cm (5¼″) in diameter for the woofer and is designed as a surface‑mount (shelf) style speaker.

Q2: What are the power handling specifications?

A2: It handles 20 W nominal (RMS) and up to 60 W maximum input power.

Q3: What is the frequency response and sensitivity?

A3: Frequency response is approximately 75 Hz to 20 000 Hz, and sensitivity is about 89 dB (1 W/1 m).

Q4: What driver materials and configuration does it use?

A4: It features an IMPP™ composite‑cone woofer, along with a horn‑midrange (≈27 mm) and horn‑tweeter (≈19 mm) to cover mid/high frequencies.

Q5: Is the TS‑X150 suitable for installing in a car in Pakistan (Karachi)?

A5: It can be used, particularly for custom shelf or rear‑deck mounting. However:

It may not fit standard door speaker cut‑outs without modification because it is surface‑mount style.
Because of the lower power rating (20 W nominal), you’ll want to pair it with a clean head‑unit or amplifier to avoid distortion.
Check availability locally and ensure wiring and mounting hardware are suitable for your vehicle.
