Description
DS18 SQBASS8
The SQBASS8 is an 8-inch subwoofer designed to provide deep, clean, and punchy bass for car audio systems and compact setups. Engineered for efficient low-frequency response, it delivers powerful bass performance with minimal distortion, making it suitable for daily driving and moderate SPL use. Built with a durable cone, reinforced surround, and high-quality voice coil, the SQBASS8 ensures reliable performance and long-lasting durability. Its compact design allows for easy integration into a variety of enclosures, making it ideal for users seeking strong low-end impact without compromising vehicle space.
Specifications
General Specs
| Category | Specification |
|---|---|
| SKU | SQBASS8 |
| Speaker Type / Size | 8″ |
| Total RMS Power Handling | 150W |
| Total MAX Power Handling | 800W |
| Sensitivity (1W/1m) | 79 dB |
| Frequency Response | 36–300 Hz |
| Remote Knob Cable Length | 16 ft / 5 m |
| Remote Knob Adjust Range | 0–30 dB |
| Auto Turn-On | Yes, Signal Sensing |
Speaker Specifications
| Attribute | Specification |
|---|---|
| Cone Material | Polypropylene |
| Surround Material | Rubber |
| Basket Material | Steel |
| Magnet Material | Ferrite |
| Body / Housing Material | Aluminum |
Amplifier Specifications
| Attribute | Specification |
|---|---|
| Amplifier Class | Digital |
| Amplifier Type | Subwoofer Monoblock |
| Number of Channels | 1Ch |
| Minimum Impedance | 2 Ohm |
| Signal to Noise Ratio | >80 dB |
| Total Harmonic Distortion (THD) | <0.5% |
| Low Level Input Range | 0.1–3.5 V |
| High Level Input | 0.3–10 V |
| Selectable X-Over | LPF Fixed |
| X-Over Filter Range | 50–150 Hz |
| Bass Boost Range | 0–12 dB |
| Bass Boost Frequency | 50 Hz |
| Infrasonic Filter | 30 Hz Fixed |
| Phase Selector | 0–180° |
| LED Indicator | Power / Protect |
| Power Input Terminal Size | 8 Ga |
| Fuse Size | 25A |
| Remote Level Control | Yes, Included |
| Thermal Protection | Yes |
| Over-Load Protection | Yes |
| DC Output Protection | Yes |
| Short Circuit Output Protection | Yes |
| Voltage Input Protection | Yes |
Measurements
| Dimension / Attribute | Specification |
|---|---|
| Overall Height | 3″ / 77mm |
| Overall Width | 9.64″ / 245mm |
| Overall Length | 11.42″ / 290mm |
| Gross Single Unit Weight | 13 lbs |
| Single Unit Box Dimensions (W×L×H) | 16.75 × 12.5 × 5.75″ |
| Quantity of Units in Master Carton | 2 |
| Gross Master Carton Weight | 27.5 lbs |
| Master Carton Dimensions (W×L×H) | 17.5 × 12.5 × 13.75″ |
Product Overview
8” Amplified Under Seat Car Subwoofer 600W
Bring the heart pounding bass you crave to any vehicle with DS18’s SQBASS8! This game-changing subwoofer will redefine your in-car audio experience!
The SQBASS8, engineered with a slim and compact design to bring bass to all builds, handles a mind-blowing 150W of RMS power. This allows the true force of the SQBASS8’s impressive frequency response ranging from 20Hz to 150Hz to be felt. This subwoofer brings an unmatched depth and richness to all your favorite tracks.
Although extremely powerful, the SQBASS8 also exemplifies the DS18 standard of precision and control in your audio system. The SQBASS8 features a state-of-the-art, digitally optimized subwoofer with a built-in 2-Ohm amplifier, ensuring unparalleled efficiency and accuracy in bass reproduction. To further elevate the SQBASS8 experience, the experts at DS18 have included a bass remote control, placing you in the driver’s seat of your build’s audio. Fine-tune your bass to match every song and mood.
When it comes to performance, the SQBASS8 reigns supreme. The versatile input sensitivity ranges from high level 300mV-10V to low level 100mV-3.5V, accommodating a wide array of audio setups with ease. With a fully adjustable low pass filter spanning from 50Hz to 150Hz and a bass boost range of 0 to 12dB, you have complete control over your soundstage, and the ability to make your bass perfect.
What sets the SQBASS8 apart from its competition is its ability to seamlessly be integrated into any build without sacrificing space or sound quality. DS18’s engineers design products for their family of audio enthusiasts, ensuring that even with limited space, you will feel the thunder of every heavy bass note.
