Description
DS18 PRO-X12.4M
The PRO‑X12.4M is a 12″ professional midrange loudspeaker engineered to deliver clear, detailed midrange frequencies with high efficiency and strong output. Its robust motor structure and optimized cone design provide focused vocal clarity and smooth midrange response, making it ideal for pro audio systems, PA setups, and custom car audio installations where enhanced midrange performance and presence are needed.
Specifications
| Specification | Value |
|---|---|
| SKU | PRO X12 4M |
| Nominal Diameter | 12 inch 308 mm |
| Nominal Impedance | 4 ohms |
| RMS Power Handling | 450 Watts |
| Maximum Power Handling | 900 Watts |
| Sensitivity 1w 1m | 97.5 dB |
| Frequency Response | 63.5 Hz to 11.3 kHz |
| Recommended Hi Pass Crossover | 120 Hz |
| Sold In | Piece |
CONSTRUCTION SPECIFICATIONS
| Specification | Value |
|---|---|
| Voice Coil Diameter | 2.5 inch 65.5 mm |
| Voice Coil Former Material | Kapton |
| Winding Material | CCAW |
| Basket Material | Steel |
| Magnet Weight | 60 oz |
THIELE AND SMALL PARAMETERS
| Parameter | Value |
|---|---|
| Vas | 23.78 L |
| Xmax | 10.5 mm |
| Fs | 64.6 Hz |
| Qms | 2.2 |
| Qes | 0.485 |
| Qts | 0.392 |
| Re | 3.2 ohms |
MEASUREMENTS AND PACKAGING
| Specification | Value |
|---|---|
| Overall Diameter | 12.12 inch 308 mm |
| Front Mount Baffle Cutout | 10.9 inch 278 mm |
| Mounting Depth | 4.96 inch 126 mm |
| Overall Depth | 5.35 inch 136 mm |
| Product Weight | 11 lbs |
| Product Dimensions | 12.75 x 12.75 x 5.5 |
| Master Carton Weight | 23.5 lbs |
| Master Carton Dimensions | 13.75 x 13.75 x 12.25 |
| Master Carton Quantity | 2 |
Product Overview
12” Mid-Range Loudspeaker 450W RMS 4-Ohm
Step into the world of powerful, high-quality sound with DS18’s PRO-X12.4M 12” Mid-Range Loudspeaker! The PRO-X12.4M delivers a concert-like audio experience without any distortion, making it an excellent choice for audiophiles and music enthusiasts alike.
With a high 97.5dB sensitivity, the PRO-X12.4M lets you crank up the volume without any sound distortion. The 63Hz to 5KHz frequency range provides richer and more accurate tones that any audiophile will immediately notice, making these loudspeakers an excellent choice for those who want to experience music the way it was meant to be heard.
The DS18 PRO-X12.4M can handle up to 450W RMS, making it capable of handling consistent and heavy usage. The hefty 60 Oz ferrite magnet and 2.5” voice coil make for a powerful combination, ensuring that every beat is heard and handled efficiently.
Whether you’re listening to your favorite album or enjoying a live concert, the DS18 PRO-X12.4M will take your audio experience to the next level. Its compact size and 5.35” mounting depth make it easy to install in your car, truck, or home, while its powerful performance ensures that you’ll enjoy high-quality sound for years to come.
DS18’s PRO-X12.4M is a high-quality midrange loudspeaker that delivers crystal-clear audio and powerful performance. Its high sensitivity, wide frequency range, and impressive power handling make it an excellent choice for audiophiles and music enthusiasts who want to enjoy loud, clear music without any distortion. Order your DS18 PRO-X12.4M today and experience the thrill of powerful, high-quality sound!
