Description
DS18 PRO-EXL108
The PRO-EXL108 is a 10″ professional full-range/mid-bass loudspeaker engineered for balanced, high-output audio performance with strong low-frequency presence and clear midrange response. Designed with a reinforced cone, rugged motor assembly, and optimized voice coil, it delivers dependable sound quality and efficiency — ideal for pro audio systems, PA setups, car audio upgrades, and custom installations that require reliable full-range sound with emphasis in the mid-bass band.
Specifications
| Specification | Value |
|---|---|
| SKU | PRO-EXL108 |
| Nominal Diameter | 10 inch |
| Nominal Impedance | 8 ohm |
| RMS Power Handling | 600W |
| Maximum Power Handling | 1200W |
| Sensitivity (1w/1m) | 97 dB |
| Frequency Response | 74Hz – 11.5KHz |
| Recommended Hi-Pass Crossover | 120 Hz |
Construction Specifications
| Specification | Value |
|---|---|
| Voice Coil Diameter | 76.5mm (3″) |
| Voice Coil Former Material | Kapton |
| Winding Material | CCAW |
| Basket Material | Aluminum |
| Magnet Weight | 80 oz |
Thiele & Small Parameters
| Parameter | Value |
|---|---|
| Vas | 4.8217 L |
| Xmax | 12.5 mm |
| Fs | 129.4 Hz |
| Qms | 1.347 |
| Qes | 0.578 |
| Qts | 0.405 |
| Re | 5.2 ohms |
Measurements & Packaging
| Specification | Value |
|---|---|
| Overall Diameter | 10.3″ (261mm) |
| Front Mount Baffle Cutout | 9.13″ (232mm) |
| Mounting Depth | 4.9″ (119mm) |
| Overall Depth | 5.1″ (129mm) |
| Product Weight | 16 lbs |
| Product Dimensions | 10.75 × 10.75 × 5.5 in |
| Master Carton (M/C) Weight | 34 lbs |
| Master Carton (M/C) Dimensions | 11.5 × 11.5 × 12 in |
| Master Carton Quantity | 2 |
| Sold In | Piece |
Product Overview
10″ Mid-Range Loudspeaker 1200 Watts @ 8-Ohm
Experience car audio like never before with DS18’s PRO-EXL108! The EXL series was designed for the audiophile who demands EXTREMELY LOUD sound reproduction with no distortion.
Built with the latest in DS18 technology and constructed with only the best materials, this leading midrange series reproduces cleaner and LOUDER midrange, mid-bass, and vocal frequencies than any other loudspeaker in its class.
The PRO-EXL108 features an oversized tooled basket with brilliant red and brushed aluminum logos, making it the perfect addition to any custom car audio setup that likes it LOUD.
With an RMS of 600W and a MAX of 1200W, this midrange loudspeaker can handle even the most demanding audio setups. The PRO-EXL108 is constructed with large push-style connections that allow for easy wiring and maximum power flow from your amplifier. This means you can enjoy the full power of your system without any degradation in quality. The frequency response of 74Hz-12KHz ensures that you’ll hear every detail of your music, while the 92dB sensitivity ensures that you can turn the volume all the way up!
DS18’s PRO-EXL108 is available in an 8-ohm configuration, which reduces overall power consumption heat generated by your system. In addition to the 8-ohm configuration, the PRO-EXL 10″ Mid-Range Loudspeaker is also available in a 4-ohm configuration.
So why settle for less when you can have the best? Upgrade your car audio system today with the DS18 PRO-EXL108 for the ultimate in sound quality and performance!
