Name: DS18 PRO-EXL104MB
SKU: PRO-EXL104MB
Availability: InStock

Description

DS18 PRO-EXL104MB

The PRO-EXL104MB is a 10″ professional mid-bass loudspeaker engineered for powerful mid-bass output and reliable performance in demanding audio systems. Featuring a reinforced cone, rugged motor structure, and optimized voice coil, it delivers punchy low-frequency response with clear midrange detail — ideal for pro audio systems, PA setups, custom car audio builds, and SPL-oriented installations. Its durable build ensures consistent performance even at high volume levels.

Specifications

Specification	Value
SKU	PRO EXL108MB
Nominal Diameter	10 inch
Nominal Impedance	4 ohms
RMS Power Handling	600 Watts
Maximum Power Handling	1200 Watts
Sensitivity 1w 1m	96 dB
Frequency Response	72 Hz to 10.5 kHz
Recommended Hi Pass Crossover	80 Hz
Sold In	Piece

CONSTRUCTION SPECIFICATIONS

Specification	Value
Voice Coil Diameter	3 inch 76.5 mm
Voice Coil Former Material	Kapton
Winding Material	CCAW
Basket Material	Aluminum
Magnet Weight	80 oz

THIELE AND SMALL PARAMETERS

Parameter	Value
Vas	15.507 L
Xmax	10 mm
Fs	72.8 Hz
Qms	4.5
Qes	0.412
Qts	0.377
Re	3.3 ohms

MEASUREMENTS AND PACKAGING

Specification	Value
Overall Diameter	10.3 inch 261 mm
Front Mount Baffle Cutout	9.13 inch 232 mm
Mounting Depth	4.9 inch 119 mm
Overall Depth	5.1 inch 129 mm
Product Weight	17.5 lbs
Product Dimensions	11 x 11 x 6
Master Carton Weight	36 lbs
Master Carton Dimensions	11.75 x 11.75 x 13.5
Master Carton Quantity	2

Product Overview

10″ Mid-Bass Loudspeaker 1200 Watts @ 4-Ohm

Turn up your car’s audio system with the DS18 PRO-EXL104MB Mid-Bass Loudspeaker! The EXL series was designed for serious pro audio enthusiasts who demand nothing but the best in EXTREMELY LOUD sound reproduction. The EXL series loudspeakers are the epitome of competition-quality reproduction and dynamic sound performance.
Crafted with a non-pressed paper cone and cloth-edge surround, the PRO-EXL104MB is engineered with pure DS18 technology to reproduce LOUDER mid-bass frequencies that you can feel.
With an RMS of 600W and a MAX of 1200W, this 10” mid-bass loudspeaker can handle even the most demanding audio setups. The PRO-EXL104MB is constructed with large push-style connections that allow for easy wiring and maximum power flow from your amplifier. This means you can enjoy the full power of your system without any degradation in quality. The frequency response of 85Hz-12KHz ensures that you’ll hear every detail of your music, while the 96dB sensitivity ensures your sound is reproduced LOUD and clear!
Not only is this speaker a powerhouse, but it’s also designed with convenience in mind. The large push-style connections make it easy to install, and its lightweight construction ensures that it won’t weigh down your audio system. DS18’s PRO-EXL104MB is available in a 4-ohm configuration, which allows greater power output from your amplifier, improved efficiency, and higher compatibility between a wider range of amplifier types. In addition to the 4-ohm configuration, the PRO-EXL 10″ Mid-Bass Loudspeaker is also available in an 8-ohm configuration.
So why settle for less when you can have the best? Upgrade your car audio system today with the DS18 PRO-EXL104MB for the ultimate in sound quality and performance!
