Description
DS18 PRO-EXL104
The PRO‑EXL104 is a 10″ professional full‑range/mid‑bass loudspeaker designed for balanced, high‑efficiency sound with solid midrange and bass response. Built with a reinforced cone, optimized motor structure, and durable voice coil, it delivers dependable performance and clear audio across a wide frequency range — making it ideal for car audio systems, pro audio setups, PA installations, and custom audio builds.
Specifications
| Specification | Value |
|---|---|
| SKU | PRO-EXL104 |
| Nominal Diameter | 10″ |
| Nominal Impedance | 4 ohms |
| RMS Power Handling | 600W |
| Maximum Power Handling | 1000W |
| Sensitivity (1w/1m) | 96 dB |
| Frequency Response | 85Hz – 12 KHz |
| Recommended Hi-Pass Crossover | 100 Hz |
Construction Specifications
| Specification | Value |
|---|---|
| Voice Coil Diameter | 3″ (76.5 mm) |
| Voice Coil Former Material | Glass Fiber |
| Winding Material | CCAW |
| Basket Material | Aluminum |
| Magnet Weight | 80 oz |
Thiele & Small Parameters
| Parameter | Value |
|---|---|
| Vas | 7.5 L |
| Xmax | 11 mm |
| Fs | 103 Hz |
| Qms | 2.918 |
| Qes | 0.452 |
| Qts | 0.391 |
| Re | 3.2 ohms |
Measurements & Packaging
| Specification | Value |
|---|---|
| Overall Diameter | 10.3″ (261.5 mm) |
| Front Mount Baffle Cutout | 9.21″ (234 mm) |
| Mounting Depth | 4.68″ (119 mm) |
| Overall Depth | 5.07″ (129 mm) |
| Product Weight | 16 lbs |
| Product Dimensions | 10.75 × 10.75 × 5.5 in |
| Master Carton (M/C) Weight | 34 lbs |
| Master Carton (M/C) Dimensions | 11.5 × 11.5 × 12 in |
| Master Carton Quantity | 2 |
| Sold In | Piece |
Product Overview
10″ Mid-Range Loudspeaker 1200 Watts @ 4-Ohm
Experience car audio like never before with DS18’s PRO-EXL104! The EXL series was designed for the audiophile who demands EXTREMELY LOUD sound reproduction with no distortion.
Built with the latest in DS18 technology and constructed with only the best materials, this leading midrange series reproduces cleaner and LOUDER midrange, mid-bass, and vocal frequencies than any other loudspeaker in its class.
The PRO-EXL104 features an oversized tooled basket with brilliant red and brushed aluminum logos, making it the perfect addition to any custom car audio setup that likes it LOUD.
With an RMS of 600W and a MAX of 1200W, this midrange loudspeaker can handle even the most demanding audio setups. The PRO-EXL104 is constructed with large push-style connections that allow for easy wiring and maximum power flow from your amplifier. This means you can enjoy the full power of your system without any degradation in quality. The frequency response of 85Hz-12KHz ensures that you’ll hear every detail of your music, while the 96dB sensitivity ensures that you can turn the volume all the way up!
DS18’s PRO-EXL104 is available in a 4-ohm configuration, which allows greater power output from your amplifier, improved efficiency, and higher compatibility between a wider range of amplifier types. In addition to the 4-ohm configuration, the PRO-EXL 10″ Mid-Range Loudspeaker is also available in an 8-ohm configuration.
So why settle for less when you can have the best? Upgrade your car audio system today with the DS18 PRO-EXL104 for the ultimate in sound quality and performance!
