Pioneer ND‑BC011

Description

Pioneer ND‑BC011

The Pioneer ND‑BC011 is a universal front/rear‑view camera designed for integration with aftermarket in‑dash receivers that support composite video inputs. It features a 1/3″ CMOS colour image sensor (≈ 968 × 488 resolution) offering a wide horizontal field of view (~155°) and vertical angle (~125°), enabling broad visual coverage behind or ahead of your vehicle. Low‑light capable (around 0.01 lux) and supplied with mounting hardware including a licence‑plate bracket and long video cable, it’s built for flexible installation across many vehicle types.

Specifications

ASSISTANCE CAMERA

ASSISTANCE FEATURES

About The Product

The ND-BC011 Universal Rearview/Backup Camera is compatible with Pioneer audio/video in-dash receivers that feature a rear-view camera input. It offers a wide-angle view of 155 degrees horizontally and 125 degrees vertically, with a resolution of over 470,000 pixels for detailed imagery. The ND-BC011 is equipped with a CMOS (Complementary Metal Oxide Semiconductor) sensor that provides improved resolution and glare reduction during daytime use, as well as enhanced low-light capability for nighttime use. Also included is a license plate bracket for easy installation.

Installation Flexibility

This backup camera utilizes the vehicle’s power supply with minimal connections for easier installation, and its compact size allows for hassle-free mounting. It also includes a 10-meter cable for installation on long trucks, SUVs, and recreational vehicles. To assist with the installation process, we designed this camera with small in-line pen-type connectors, making it easier to route the wire into the cabin without the need for large holes.

Improved Visibility

A wide-angle 155 degree horizontal and 125 degree vertical angle lens allows viewing more objects. The 1/3” (8.5mm) color CMOS sensor delivers improved resolution and glare reduction during daytime use with improved low-light capability for nighttime use.
