Memphis MXA480.4M

Description

Memphis MXA480.4M

The MXA480.4M is a high-power 4-channel marine amplifier engineered for powersports, boats, and other outdoor audio systems. It delivers clean, robust sound for multiple speakers or bridged subwoofer configurations. Built with a fully sealed, weather-resistant chassis and conformal-coated circuitry, the MXA480.4M is designed to withstand water, salt, mud, and vibrations. Its adjustable crossovers and flexible high/low-level inputs make it easy to integrate into factory or custom audio setups.

Features:

• 4-channel marine/powersports amplifier
• 80 watts RMS x 4 at 4 ohms (120 watts RMS x 4 at 2 ohms)
• 240 watts x 2 bridged at 4 ohms
• Class D amp technology
• variable high- and low-pass filters
• 8-gauge wiring kit (sold separately) recommended
• two sets of preamp inputs
• frequency response: 10-40,000 Hz
• dimensions: 10-3/4″W x 2-3/8″H x 6-1/2″D

Specifications:

• RMS Power Output (Watts x Channels): 80 x 4
• Frequency Response at Rated RMS Power: 20-20k Hz
• THD at Rated RMS Power: 1%
• Signal to Noise Ratio: 95 dB
• Input Voltage: 14.4v
• Peak Power Output (Watts x Channels): N/A
• Power at 2 Ohms (Watts x Channels): 120 x 4
• Bridged Power (Watts x Channels): 240 x 2
• Minimum Impedance Bridged: 4
• Minimum Impedance Unbridged: 2
• Amplifier Class: D
• Low-Pass Crossover Frequency: 40-4000 Hz
• Low-Pass Slope (dB/octave): 12dB/oct
• High-Pass Crossover Frequency: 40-4000 Hz
• High-Pass Slope (dB/octave): 12dB/oct
• Bass Boost: 0-12dB
• Bass Boost Frequency: 45 Hz
• Fan Cooled: No
• Fuse Rating: 50
• Speaker Level Inputs: No
• Preamp Outputs: No
• Height (inches): 2-3/8
• Width (inches): 10-3/4
• Depth (inches): 6-1/2
