Description
DS18 X2BT
The X2BT is a high-performance car audio amplifier designed to deliver powerful and clear sound to your car’s audio system. Engineered for efficiency and reliability, it ensures maximum output without distortion, even at high volumes. The X2BT features advanced circuitry that provides consistent power to your speakers, enhancing bass response, midrange clarity, and overall audio fidelity. Its compact and durable design makes it easy to install in most vehicles, while built-in protection mechanisms safeguard your system from overheating, short circuits, and voltage fluctuations, ensuring long-lasting performance.
Specifications
| Specification | Details |
|---|---|
| Total Watts (Peak) | 1140 W |
| RMS Power @ 4 Ω | 2 × 140 W |
| RMS Power @ 2 Ω | 2 × 230 W |
| RMS Power @ 4 Ω Bridge | 380 W |
Audio
| Specification | Details |
|---|---|
| Frequency Response | 20 Hz – 20 kHz |
| Signal to Noise Ratio | 90 dB |
| Efficiency @ 4 Ω | 80% |
| Damping Factor | 200 |
| Total Harmonic Distortion (THD) | 0.20% |
| Low Level Input Range | 0.2 – 5 V |
| Selectable X-Over | LPF / FLAT / HPF |
| X-Over Filter Range | 40 Hz – 400 Hz |
Features
| Feature | Details |
|---|---|
| Amplifier Class | Digital (D) |
| Amplifier Type | Stereo Full Range |
| Number of Channels | 2 |
| Minimum Impedance | 2 Ω Stereo / 4 Ω Bridge |
| LED Indicator | Power / Protect |
| Power Input Terminal Size | 8 GA |
| Fuse Size | 40 A |
| Thermal Protection | Yes |
| Over-Load Protection | Yes |
| DC Output Protection | Yes |
| Short Circuit Output Protection | Yes |
| Voltage Input Protection | Yes |
| Body Color / Finish | Brushed Black Aluminum |
| Ultra Compact Size | Yes |
| Stable / Reliable Four Layers PCB with SMC Technology | Yes |
| 2 or 4 Channel Input Selector | No |
| Quality Control Verification | Yes, using Audio Precision Instruments |
| Audio Input with Automatic Switching BT / RCA | Yes |
Bluetooth Specifications
| Specification | Details |
|---|---|
| Version | 5.1 |
| Services | A2DP 1.3.1 |
| Bluetooth Name | DS18 X2BT |
| Range | Up to 60 ft / 18 m |
| Supported Devices | iOS / Android |
| Audio Codec | SBC / AAC |
Measurements
| Dimension | Size |
|---|---|
| Overall Length | 5.54″ / 140.8 mm |
| Overall Width | 3.24″ / 82.4 mm |
| Overall Height | 1.37″ / 34.8 mm |
| Heatsink Length | 4.75″ / 120.8 mm |
Product Overview
2-Channel Class D Full-Range Amplifier with Bluetooth Streaming
The latest addition to DS18’s X Series is the X2BT: an ultra-compact 2-channel amplifier engineered for modern audio systems that demand Bluetooth connectivity, digital tuning, and efficient power delivery in a tight package.
Built-In Bluetooth Streaming
Thanks to onboard Bluetooth 5.1, the X2BT allows you to stream high-quality audio directly from your phone or device. This means your music is always accessible!
Full Range Flex
The X2BT is optimized for full-range performance, making it ideal for mids, highs, or even small subwoofer setups in tight spaces.
Power Output @ 4Ω: 2 x 140W RMS
Power Output @ 2Ω: 2 x 230W RMS
Bridged @ 4Ω: 1 x 380W RMS
Compact + Weather-Resistant
The rugged housing is designed for tough environments, with a compact chassis that fits anywhere. It’s perfect for powersports builds where space and reliability matter.
Upgrade your ride with wireless control and clean power! DS18’s X2BT is the go-to amplifier for flexible, high-performance audio.
