Description
DS18 PRO-TW750C-8/BK
The PRO-TW750C-8 is a high-performance 4-inch super bullet tweeter designed to deliver clear, powerful high-frequency sound for car audio systems and custom installs. Featuring a 1.5″ titanium voice coil, oversized ferrite magnet, and CNC-machined aluminum bullet housing, it offers 150 W AES, 200 W RMS (program), and up to 400 W peak power handling with 8-ohm impedance and 109 dB sensitivity for crisp, dynamic treble performance. The frequency response spans approximately 900 Hz to 20 kHz, and a 3.3 µF bass blocker helps protect the tweeter by filtering out low frequencies. Its compact design and shallow mounting depth make installation easy in doors, dashboards, pillars, or custom pods, adding depth and clarity to your audio system’s high-end output.
Specifications
| Parameter | Details |
|---|---|
| SKU | PRO-TW750C-8/BK |
| Nominal Diameter | 4″ / 103 mm |
| Nominal Impedance | 8 Ohms |
| AES Power Handling | 150 W |
| Program Power Handling | 200 W |
| Peak Power Handling | 400 W |
| Sensitivity (1W/1M) | 109 dB |
| Frequency Response | 900 Hz – 20 kHz |
| Recommended Hi-Pass Crossover | 3 kHz |
| Sold In | Single |
Body / Features
| Parameter | Details |
|---|---|
| Filter (Bass Blocker) | 3.3 µF / 100 V |
| Body Material | Aluminum |
| Body Color / Finish | Aluminum / Machined – Sandblaster Black |
| Faceplate Color / Finish | Aluminum / Machined – Sandblaster Black |
| Bullet Material | CNC Aluminum |
Motor
| Parameter | Details |
|---|---|
| Voice Coil Diameter | 1.5″ / 38 mm |
| Voice Coil Former Material | KSV |
| Winding Material | CCAW |
| Diaphragm Material | Titanium |
| Magnet Material | Ferrite |
| Magnet Size | 3.5″ × 1″ / 90 × 25 mm |
| Magnet Weight | 20.1 Oz |
Product Overview
4″ Super Bullet Tweeter with 1.5″ Titanium Voice Coil And Oversized Ferrite Magnet
Next level quality is possible with DS18’s PRO-TW750C-8, a 4-inch bullet tweeter designed for precision. Built for detailed high frequencies, the PRO-TW750C-8 transforms every audio setup into a masterpiece.
Featuring a robust titanium voice coil, the PRO-TW750C-8 offers premium sound reproduction with AES Power Handling at 150W and Program Power Handling at 200W. Its oversized ferrite magnet ensures high sensitivity and consistent performance across a wide frequency range of 900Hz–20KHz. To optimize its performance, we’ve paired it with a 3.3uF bass blocker ensures that low-frequency sounds are filtered out, preventing distortion and protecting the tweeter from damage.
Crafted for durability, this tweeter features a CNC aluminum bullet and sandblasted body, coming in either a sleek silver or bold black color. With an impressive sensitivity of 109dB, 8-ohm impedance, and a compact 2.5″ mounting depth, the PRO-TW750C-8 integrates effortlessly into various systems for a seamless audio upgrade.
For those who demand the best in sound and design, the DS18’s PRO-TW750C-8 is the ultimate choice.
