DS18 PRO-NS6

The DS18 PRO-NS6 is a 6.5-inch component speaker system designed for high-quality car audio performance. Featuring a 4-ohm impedance and a neodymium tweeter, it delivers clear and detailed midrange and high-frequency audio, ensuring precise vocals and instrument separation. Built with durable materials, the PRO-NS6 provides reliable performance for daily driving, custom audio builds, and multi-way systems. Ideal for integration with subwoofers and other speakers, it offers dynamic and immersive sound for a professional in-car listening experience.


Specifications

Specification Details
SKU PRO-NS6
Nominal Diameter 6.5 inch
Nominal Impedance 8 Ohms
RMS Power Handling 150 Watts
Maximum Power Handling 300 Watts
Sensitivity (1W/1M) 94 dB
Frequency Response 100 Hz – 12 KHz
Recommended Hi Pass Crossover 180 Hz
Sold In Piece

Motor Specifications
Specification Details
Voice Coil Diameter 1.5 inch / 38.6 mm
Voice Coil Former Material KSV
Winding Material Copper
Basket Material Steel
Magnet Weight 1.79 Oz

Thiele and Small Parameters
Parameter Value
Vas 4.8 L / 0.169 ft3
Xmax 2 mm
Fs 139 Hz
Qms 5.781
Qes 1.245
Qts 1.025
Re 6.5 Ohms

Measurements and Packaging
Measurement Details
Overall Diameter 6.57 inch / 167 mm
Front Mount Baffle Cutout 5.7 inch / 145 mm
Mounting Depth 1.96 inch / 50 mm
Overall Depth 2.2 inch / 56 mm
Product Weight 2 lbs
Product Dimensions 7 x 7 x 3 inch
Master Carton Weight 17.5 lbs
Master Carton Dimensions 14.5 x 14.5 x 6.75 inch
Master Carton Quantity 8

Product Overview

6.5” Shallow Neodymium Mid-Range Loudspeaker 300W 8-Ohm

Are you looking for maximum loudness and volume without sacrificing space? Look no further than the PRO-NS6, DS18’s Shallow Neodymium Mid-Range Loudspeaker. This 6.5-inch mid-range loudspeaker boasts a high-efficiency 1.5-inch voice coil that handles a whopping 150W RMS and 300W peak power for extreme loudness and frequency precision.
What truly sets the PRO-NS6 apart is its shallow mounting depth of only 1.96 inches, making it the perfect solution for those tight spaces where full-size speakers just won’t fit. The PRO-NS6’s sleek and slim design doesn’t skimp on performance, either. With a sensitivity rating of 94dB, the PRO-NS6 is incredibly efficient at converting power into sound, which means that you can get much louder sound output from your amplifier compared to less efficient speakers. This is a huge advantage for anyone who wants to play their music at high volumes without having to crank up their amplifier to maximum power.
The PRO-NS6’s materials, including its glossy red steel basket, neodymium magnet, paper cone, copper voice coil former, and cloth dust cap, all work together to provide an exceptional balance of durability and sound quality. Resulting in a speaker that delivers accurate, powerful, and detailed sound, while still maintaining its structural integrity for years to come.
The PRO-NS6 is the ultimate choice for anyone seeking exceptional sound quality and durability in a compact and slim package. Upgrade your audio experience today and take your listening pleasure to the next level with the PRO-NS6.

Reviews

There are no reviews yet.

Be the first to review “DS18 PRO-NS6”

Your email address will not be published. Required fields are marked *

Questions and Answers

Q1: What is the DS18 PRO-NS6?

A1: It is a 6.5-inch component speaker system with a 4-ohm impedance and neodymium tweeter, designed for clear mids and highs in car audio systems.

Q2: What type of sound does it produce?

A2: It delivers precise midrange and high-frequency audio with strong vocal clarity and detailed instrument reproduction.

Q3: Can it be used in multi-way car audio systems?

A3: Yes, it pairs seamlessly with subwoofers and other speakers for full-range car audio setups.

.

Q4: Is it suitable for compact installations?

A4: Yes, its compact design allows installation in a variety of car interiors while maintaining high-quality sound.

Q5: Is it reliable for daily use?

A5: Absolutely. Its durable construction and efficient design ensure consistent performance for everyday driving and long-term use.
