Description
DS18 PRO-HY6MSL
The DS18 PRO-HY6MSL is a 6.2-inch hybrid midrange loudspeaker available in 2-ohm, 4-ohm, and 8-ohm configurations, designed to deliver powerful, crystal-clear vocals and midrange performance in high-output car audio systems. Engineered for efficiency and durability, it produces strong, detailed sound with excellent projection and clarity, making it ideal for door panels, custom builds, and SPL setups. Its rugged construction ensures reliable performance under demanding conditions, while the multiple impedance options provide flexible wiring compatibility for different amplifier setups. The PRO-HY6.2MSL is perfect for enthusiasts seeking loud, clean, and dynamic midrange response in professional-grade audio systems.
Specifications
| Specification | Details |
|---|---|
| SKU | PRO-HY6MSL |
| Nominal Diameter | 6.5 inch / 165.1 mm |
| Nominal Impedance | 8 Ohms |
| RMS Power Handling | 150 Watts |
| Maximum Power Handling | 300 Watts |
| Sensitivity (1W/1M) | 93 dB |
| Frequency Response | 120 Hz – 20 kHz |
| Recommended Hi Pass Crossover | 140 Hz |
| Number of Ways | 2 Way |
| Sold In | Single |
| Grill Included | Yes |
Woofer Specifications
| Specification | Details |
|---|---|
| Voice Coil Diameter | 1.5 inch / 38.6 mm |
| Voice Coil Former Material | KSV |
| Winding Material | CCAW |
| Cone Material | Paper |
| Surround Material | Cloth |
| Basket Material | Steel |
| Basket Color / Finish | Glossy Red |
| Magnet Material | Ferrite |
| Magnet Weight | 17.5 Oz |
| Displacement Volume | Not Specified |
Thiele and Small Parameters
| Parameter | Value |
|---|---|
| Vas | 3.45 L / 0.121 ft³ |
| Xmax (One Way) | 2 mm |
| Fs | 161 Hz |
| Qms | 7.653 |
| Qes | 1.496 |
| Qts | 1.252 |
| Mms | 6.875 g |
| Cms | 129.952 mm/N |
| BL | 5.621 |
| Le | 10.78 mH |
| Sd | 136.848 cm² |
| Re | 6.5 Ohms |
| Mmd (Without Air) | 5.955 g |
Driver Specifications
| Specification | Details |
|---|---|
| Voice Coil Diameter | 1 inch / 25.4 mm |
| Voice Coil Former Material | Kapton |
| Winding Material | CCAW |
| Diaphragm Material | Titanium |
| Magnet Material | Neodymium |
| Horn Diameter | 3 inch / 76.2 mm |
Speaker Measurements
| Measurement | Details |
|---|---|
| Overall Diameter | 6.92 inch / 176 mm |
| Overall Depth | 3.52 inch / 89.5 mm |
| Front Mount Baffle Cutout | 5.6 inch / 142 mm |
| Mounting Depth | 2.77 inch / 70.5 mm |
| Motor Diameter | 4.33 inch / 110 mm |
Shipping Information
| Parameter | Details |
|---|---|
| Gross Single Unit Weight | 3.75 lbs |
| Single Unit Box Dimensions (L x W x H) | 7.25 x 7.25 x 4.25 inch |
| Quantity per Master Carton | 8 |
| Gross Master Carton Weight | 32 lbs |
| Master Carton Dimensions (L x W x H) | 15.25 x 15.25 x 9.5 inch |
Product Overview
6.5” Hybrid Slim Loudspeaker With 1” Compression Driver Horn
Get LOUD in tight spaces with DS18’s PRO-HY6MSL—the slim-mount hybrid speaker made for motorcycles, ATVs, Slingshots, and more.
Hybrid Power in a Compact Package
The PRO-HY6MSL combines a powerful 6.5” midrange woofer with a 1” titanium compression driver horn, packing serious output into a slim 2.77” mounting depth. This speaker cuts through wind noise or engine rumble LOUD and clear with 150W RMS / 300W MAX power handling and a bold 93dB sensitivity across 120Hz-20KHz.
High-End Components, No Compromise
Crafted with a paper cone, cloth surround, and a 1.5” KSV voice coil, this loudspeaker delivers smooth midrange and vocal response. The steel basket and 17.5oz ferrite magnet give it structure and strength, while the titanium diaphragm and neodymium motor in the horn ensure razor-sharp highs that carry far and stay crisp. This 8-ohm setup gives you more flexibility when building or expanding multi-speaker systems.
Designed for Real Riders
This speaker is for real riders who want clean sound in performance machines. If your vehicle has room for 6.5’s, the PRO-HY6MSL belongs in it.
