Description
DS18 PRO-GRT8BK
The DS18 PRO‑GRT8BK is an 8″ black protective speaker grille from DS18’s PRO Series, designed to safeguard your 8‑inch speakers from dust, debris, moisture, and accidental impacts while preserving clean audio performance. Constructed from durable black‑finished metal mesh with a rigid frame, the PRO‑GRT8BK offers reliable protection for both car audio and professional sound systems without interfering with sound dispersion or clarity. Its universal mounting design makes installation easy on most standard 8″ speakers, making it a great choice for custom installs, daily audio setups, and show systems. Combining rugged protection with a sleek black look, the PRO‑GRT8BK enhances both the durability and visual appeal of your speaker setup.
Specifications
| Category | Details |
|---|---|
| SKU | PRO-GRT8BK |
| Nominal Diameter | 8″ / 203.2mm |
| Nominal Impedance | 4 Ohm |
| AES Power Handling | 125W |
| Program Power Handling | 250W |
| Peak Power Handling | 500W |
| Sensitivity (1W/1m) | 98 dB |
| Frequency Response | 1.6KHz – 20KHz |
| Recommended Hi-Pass Crossover | 2KHz |
Body / Features
| Feature | Details |
|---|---|
| Sold in Pair or Single | Single |
| Body (Grill) Material | High Temperature ABS |
| Logo | Hot Stamping (Silver) |
| Body Color / Finish | Black / Gloss |
Tweeter Specifications
| Feature | Details |
|---|---|
| Type | Compression Bullet |
| Voice Coil Diameter | 1.75″ / 44.45mm |
| Voice Coil Former Material | Kapton |
| Winding Material | CCAW |
| Bullet Material | CNC Aluminum |
| Diaphragm Material | Titanium |
| Magnet Material | Neodymium (N40H) |
| Capacitor (Crossover) | Mylar 6 dB/Oct |
Measurement
| Feature | Details |
|---|---|
| Overall Diameter | 8.64″ / 219mm |
| Overall Depth | 1.87″ / 47.5mm |
| Bolt Pattern | 7.76″ / 197mm |
| Mounting Inside Ring Height | 0.24″ / 6mm |
| Mounting Outside Ring Height | 1″ / 25.5mm |
| Tweeter Wire Length | 2ft / 0.6m |
Shipping Info
| Feature | Details |
|---|---|
| Gross Single Unit Weight (lb) | 1.5 |
| Single Unit Box Dimensions (W×L×H) (inches) | 9 × 9 × 2.25 |
| Quantity of Units in Master Carton | 20 |
| Gross Master Carton Weight (lb) | 33.5 |
| Master Carton Dimensions (W×L×H) (inches) | 23 × 19 × 9.75 |
Product Overview
8″ Speaker Grill with Built-in 1.75″ Voice Coil Neodymium Bullet Tweeter 250 Watts
DS18’s PRO-GRT8BK combines stunning design, unparalleled protection, and breathtaking audio performance to elevate your car audio experience. The PRO-GRT8BK features a built-in high-powered Neodymium Super Bullet Tweeter, housing a formidable 1.75″ voice coil. Experience music the way it was meant to be heard, with unparalleled clarity and precision.
Crafted with expert attention to detail, the PRO-GRT8BK is encased in high-temperature ABS plastic, ensuring that your investment is shielded from the rigors of the road. The glossy black finish not only complements the aesthetics of any build, but it also exudes sophistication and style.
To guarantee exceptional reliability and performance, the PRO-GRT8BK underwent rigorous testing. We pushed the boundaries, subjecting it to extreme temperatures, intense vibrations, and relentless power. Rest assured DS18’s PRO-GRT8BK has been engineered to withstand the harshest conditions, delivering outstanding performance every time you turn up the volume.
Embrace the power of DS18’s PRO-GRT8BK. With a nominal impedance of 4 ohms, AES Power Handling of 125W, Program Power Handling of 250W, and Peak Power Handling of 500W, the PRO-GRT8BK delivers unrivaled performance. With a sensitivity of 98 dB, a frequency response ranging from 1.6KHz to 20KHz, and a recommended hi-pass crossover of 2KHz, prepare to be captivated by the intricacies and nuances of your favorite tracks.
Elevate your sound system to new heights, indulge in crisp highs, and protect your investment with this highly durable, glossy black speaker grill. Choose DS18’s PRO-GRT8BK and let your car audio dreams become a reality.
