Name: DS18 PRO-DRNSC1.5
SKU: PRO-DRNSC1.5
Availability: InStock

Description

DS18 PRO-DRNSC1.5

The PRO-DRNSC1.5 is a high-efficiency compression driver designed to deliver clear, powerful, and focused high-frequency sound for car audio and professional sound systems. Featuring a 1.5″ throat, it is engineered to pair with compatible horns or waveguides for improved sound projection and controlled dispersion. Its compact yet robust design allows it to handle high SPL levels while maintaining low distortion and excellent vocal clarity. Built for reliability and consistent performance, the PRO-DRNSC1.5 is ideal for SPL builds, PA setups, and custom audio systems where precise and punchy high-frequency reproduction is required.

Specifications

General Specs

Feature	Details
SKU	PRO-DRNSC1.5
Throat Diameter	1″ / 25.4 mm
Installation Type	Screw-On
Nominal Impedance	8 Ohm
AES Power Handling	80 W
Program Power Handling	160 W
Peak Power Handling	320 W
Sensitivity (1w/1m)	109 dB
Frequency Response	1K – 20KHz
Recommended Hi Pass Crossover	2KHz
Sold In	Piece

Motor / Body

Feature	Details
Voice Coil Diameter	1.5″ / 38 mm
Voice Coil Former Material	Kapton
Winding Material	Aluminum
Diaphragm Material	Polyimide
Magnet Material	Neodymium (N38H)
Magnet Weight	2.4 oz
Body Material	Aluminum
Body Color / Finish	Silver / Raw

Measurements

Feature	Details
Overall Diameter	2.52″ / 64 mm
Overall Depth	1.93″ / 49.2 mm
Bolt Pattern	2.75″ / 70 mm
Mounting Depth	1.3″ / 33 mm
Product Weight	1.1 lbs
Product Dimensions	2.75 × 2.75 × 3 in

Master Carton (M/C) Info

Feature	Details
M/C Quantity	24
M/C Weight	26.5 lbs
M/C Dimensions	11.5 × 8.5 × 6.5 in

Product Overview

1″ Screw On Compression Driver with 1.5″ Polyimide VC 8 ohm

Step into a world where audio perfection meets unbounded creativity, where your car’s audio system transforms into a concert hall thanks to your speakers immersive power. DS18’s PRO-DRNSC1.5 redefines what you thought was possible in car audio.
With a commanding 80W AES Power Handling that effortlessly scales to a staggering 320W Peak Power Handling, your music gains wings, soaring to new heights with unwavering clarity and power. The PRO-DRNSC1.5’s 109dB sensitivity makes sure your music’s quality doesn’t decrease as the volume increases. Its 1K-20KHz frequency response unveils parts of your music you never knew existed. These drivers are your ticket to a sonic adventure where the depths of bass and heights of treble combine in perfect harmony, leaving ordinary sound systems in the rear-view mirror.
Crafted with unwavering dedication, the PRO-DRNSC1.5 boasts a 1.5” voice coil that doesn’t stop working. Designed to perform at its highest potential, the PRO-DRNSC1.5 ensures enduring excellence during every jam session. Imagine the thrill of commanding your audio system, knowing that each note, each beat, and each crescendo is faithfully reproduced, providing you with an unmatched audio experience.
The PRO-DRNSC1.5 is more than just a compression driver – it’s a leap into the future of car audio. Neodymium Magnets pave the way for unprecedented efficiency and power handling, liberating your system from the confines of traditional ferrite magnets. The compact design pushes boundaries, fitting seamlessly into spaces previously untouched by high-performance drivers. Sound knows no limits at DS18, innovation and imagination unite to give you the audio experience you’ve always wanted.
It’s time to amplify your drive with DS18’s PRO-DRNSC1.5.
