Name: DS18 PRO-D22Ti.8
SKU: PRO-D22Ti.8
Availability: InStock

Description

DS18 PRO-D22Ti.8

The PRO-D22TI.8 is a high-performance 2″ throat compression driver featuring a titanium diaphragm, designed for car audio SPL systems and professional PA applications. It delivers crisp, powerful, and detailed high-frequency sound with fast transient response and minimal distortion, making it ideal for vocals, cymbals, and other treble-rich audio. With an 8-ohm impedance, it pairs seamlessly with compatible horns or waveguides to provide precise sound projection and controlled dispersion. Its durable titanium construction ensures reliable performance in demanding high-output setups, offering professional-grade treble clarity and consistency for SPL builds and PA systems.

Specifications

General Specs

Feature	Details
SKU	PRO-D22TI.8
Throat Diameter	2″ / 50.8 mm
Installation Type	Bolt-On
Nominal Impedance	8 Ohms
AES Power Handling	160W
Program Power Handling	320W
Peak Power Handling	640W
Sensitivity (1w/1m)	109 dB
Frequency Response	630Hz – 20KHz
Recommended Hi Pass Crossover	800 Hz
Sold in	Single
Filter (Bass Blocker)	10Uf / 100V
Body Material	Aluminum
Body Color / Finish	Black / Machined

Motor

Feature	Details
Voice Coil Diameter	2″ / 50.8 mm
Voice Coil Former Material	Kapton
Winding Material	CCAW
Diaphragm Material	Titanium
Magnet Material	Ferrite
Magnet Weight	35 oz

Measurements

Feature	Details
Overall Diameter	5.31″ / 135 mm
Overall Depth	2.08″ / 53 mm
Bolt Pattern / Type	4xM6 – 4″ / 102 mm

Product Overview

DS18’s PRO-D22Ti.8 is the only choice for those who demand the best from their systems. Its 2″ throat diameter ensures maximum sound projection so your music reaches every corner of the venue. The bolt-on installation type guarantees hassle-free setup so you can focus on getting LOUD!

With a nominal impedance of 8 Ohms and an AES power handling capability of 160W, DS18’s PRO-D22Ti.8 is built to integrate easily into the most demanding audio setups. Its program power handling of 320W and peak power handling of 640W ensure a dynamic and immersive listening experience.

Equipped with a 2″ voice coil made from high-quality Titanium, this compression driver provides excellent heat resistance and durability, for years of reliable performance. The titanium diaphragm delivers crystal-clear highs with exceptional accuracy, allowing you to hear every detail in your music.

The PRO-D22Ti.8 features a robust ferrite magnet that enhances efficiency and magnet weight of 35 Oz for precise control over the sound output. The aluminum body not only adds durability but also contributes to reducing unwanted resonance for cleaner sound reproduction.

Upgrade with DS18’s PRO-D22Ti.8 2″ and experience audio like never before.
