Description
DS18 PRO-3KP12.4
The DS18 PRO-3KP12 is a 12-inch high-power subwoofer available in 2-ohm, 4-ohm, and 8-ohm voice coil configurations, engineered for car audio enthusiasts who demand extreme bass performance and flexibility. Rated at 1500 W RMS (3000 W peak), it delivers deep, tight, and punchy low frequencies with exceptional clarity and impact. Its robust and durable construction ensures reliable operation for daily drivers, custom SPL builds, and professional-level car audio systems. Compatible with both sealed and ported enclosures, the PRO-3KP12 provides bass response down to approximately 28 Hz, making it ideal for setups that require immersive, high-output low-end with flexible wiring options for 2Ω, 4Ω, or 8Ω systems.
Specifications
| Specification |
Details |
| SKU |
PRO-3KP12.4 |
| Nominal Diameter |
12 inch |
| Nominal Impedance |
4 Ohms |
| RMS Power Handling |
3000 Watts |
| Maximum Power Handling |
4500 Watts |
| Sensitivity (1W/1M) |
95.8 dB |
| Frequency Response |
60 Hz – 9 kHz |
| Recommended Hi Pass Crossover |
70 Hz |
| Sold In |
Piece |
Motor Specifications
| Specification |
Details |
| Voice Coil Diameter |
4 inch |
| Voice Coil Former Material |
Fiber Glass |
| Winding Material |
CCAW |
| Basket Material |
Aluminum |
| Magnet Weight |
250 Oz |
Thiele & Small Parameters
| Parameter |
Value |
| Vas |
22.019 L |
| Xmax |
7 mm |
| Fs |
67.8 Hz |
| Qms |
10.511 |
| Qes |
0.282 |
| Qts |
0.274 |
| Re |
2.8 Ohms |
Measurements and Packaging
| Measurement |
Details |
| Overall Diameter |
12.36 inch / 314 mm |
| Front Mount Baffle Cutout |
11.18 inch / 284 mm |
| Mounting Depth |
7.2 inch / 183 mm |
| Overall Depth |
7.75 inch / 197 mm |
| Product Weight |
51 lbs |
| Product Dimensions |
15 x 15 x 11 inch |
| Master Carton Weight |
51 lbs |
| Master Carton Dimensions |
15 x 15 x 11 inch |
| Master Carton Quantity |
1 |
Product Overview
12″ PANCADAO Mid-Bass Loudspeaker 3000 Watts RMS 4-Ohm
Prepare to be blown away by DS18’s PRO-3KP12.4 PANCADÃO Mid-Bass Loudspeaker – the ultimate addition to any high-performance pro audio system. This speaker is not for the faint-hearted. With a name that means “hard-hitting bass” in Brazilian Portuguese, this speaker delivers just that.
Featuring a large high-strength ferrite magnet and reinforced aluminum basket, the PRO-3KP12.4 is built to handle insane amounts of power and get LOUD like no other. Its 3000 Watts RMS Power Handling and 4500 Watts MAX Power Handling make it one of the most powerful mid-bass speakers on the market.
But that’s not all – this speaker is a true “do-all” woofer, capable of playing an incredible range of frequencies from hard-punching mid-bass to mid-high vocals, all at an unbelievable volume. With a sensitivity of 95.8dB and a frequency response of 60Hz-9kHz, the PRO-3KP12.4 sets a new standard for sound quality.
DS18’s PRO-3KP12.4 PANCADÃO Mid-Bass Loudspeaker is designed to be versatile enough to fit in any sound system, and this is further emphasized by the range of impedances available for this speaker. The PRO-3KP12.4 is offered in a 4-Ohm configuration, which makes it compatible with a wide range of amplifiers and audio systems: but, these speakers also come in 2-ohm configurations. This flexibility in impedance options allows the speaker to work seamlessly with different audio setups, ensuring that you get the best performance out of your sound system.
If you’re looking for a speaker that will set your sound system apart from the rest, look no further than the PRO-3KP12.4 PANCADÃO Mid-Bass Loudspeaker.
