Description
DS18 NVY-CTN1
The NVY‑CTN1 is a high‑compression 2‑inch hybrid driver/tweeter designed to deliver crisp, detailed high‑frequency sound and broad audio clarity for car, powersports, or custom sound systems. Equipped with a 1‑inch aluminum PEN voice coil, neodymium magnet, and 105 dB high sensitivity, it efficiently reproduces treble with minimal distortion. Built with a 3.3 µF bass blocker filter to protect against low‑frequency overload and a durable aluminum body, the NVY‑CTN1 handles up to 100 W RMS (200 W peak) at 4 Ω impedance, making it ideal for upgrading stock systems and enhancing vocals, instruments, and high‑end audio detail. Its compact design also simplifies installation and integration.
Specifications
| Specification | Details |
|---|---|
| Nominal Diameter | 2″ / 52mm |
| Nominal Impedance | 4 ohms |
| AES Power Handling | 50W |
| Program Power Handling | 100W |
| Peak Power Handling | 200W |
| Sensitivity (1W/1m) | 105 dB |
| Frequency Response | 1.2kHz–20kHz |
| Recommended Hi-Pass Crossover | 2kHz |
| Sold In | Single |
Body / Features
| Feature | Details |
|---|---|
| Filter (Bass Blocker) | 3.3µF / 50V |
| Body Material | Aluminum |
| Body Color / Finish | Black |
| Faceplate Color / Finish | Black |
| Bullet Material | ABS |
| Terminal Type | Spade |
Motor Specifications
| Specification | Details |
|---|---|
| Voice Coil Diameter | 1″ / 25.4mm |
| Voice Coil Former Material | KSV |
| Winding Material | Aluminum |
| Diaphragm Material | PEN |
| Magnet Material | Neodymium |
| Magnet Size / Weight | 2″ x 0.2″ / 52 x 5 mm |
Measurements
| Measurement | Details |
|---|---|
| Overall Diameter | 2″ / 52mm |
| Overall Depth | 2.15″ / 54.6mm |
| Front Mount Baffle Cutout | 1.4″ / 35mm |
| Mounting Depth | 1.75″ / 44.2mm |
