Description
DS18 12PRO2500MB-8
The DS18 12PRO2500MB‑8 is a 12‑inch professional mid‑bass loudspeaker designed for high‑output car audio systems and custom audio installations that demand powerful, clear, and deep mid‑bass performance. With an 8 ohm impedance and a rugged build, it’s built for reliability and strong energy‑handling capabilities.
Specifications
| Parameter | Value |
|---|---|
| SKU | 12PRO2500MB-8 |
| Nominal Diameter | 12″ / 300 mm |
| Nominal Impedance | 8 Ω |
| RMS Power Handling | 1250 W |
| Max Power Handling | 2500 W |
| Sensitivity (1w/1m) | 99 dB |
| Frequency Response | 40 Hz – 5 kHz |
| Recommended High-Pass Crossover | 80 Hz |
| Sold As | Single |
| Grill Included | No |
Features
| Feature | Details |
|---|---|
| Interleaved Sandwich Voice Coil (ISV) | Yes |
| Improved Heat Dissipation | Yes |
| Cone Shape | Curvilinear |
| Speaker Terminals | Push Spring Loaded (8ga) |
Motor Specifications
| Parameter | Value |
|---|---|
| Voice Coil Diameter | 4″ / 101.6 mm |
| Voice Coil Former Material | Fiberglass |
| Winding Material | CCAW |
| Cone Material | Non-Pressed Paper |
| Dust Cap Material | Paper |
| Surround Material | Cloth |
| Basket Material | Aluminum |
| Basket Finish | Black |
| Magnet Material | Ferrite |
| Magnet Weight | 126 Oz |
| Displacement Volume | 1.9 L / 0.067 ft³ |
Thiele & Small Parameters
| Parameter | Value |
|---|---|
| Equivalent Volume (Vas) | 32.9 L / 1.16 ft³ |
| Excursion (Xmax) | 2 mm |
| Free Air Resonance (Fs) | 68 Hz |
| Mechanical Factor (Qms) | 7.61 |
| Electrical Factor (Qes) | 0.45 |
| Total Factor (Qts) | 0.42 |
| Mechanical Mass (Mms) | 68.86 g |
| Mechanical Compliance (Cms) | 0.08 mm/N |
| BL Factor | 19.82 |
| Voice Coil Inductance (Le) | 0.41 mH |
| Cone Area (Sd) | 539.13 cm² |
| DC Resistance (Re) | 5.9 Ω |
| Mechanical Mass w/o Air (Mmd) | 57.63 g |
Product Overview
DS18 12PRO2500MB-8
DS18’s 12PRO2500MB-8 is the ultimate choice for those seeking an unparalleled sound experience.
With a powerful 1250W RMS power handling and a MAX of 2500W, this mid-bass loudspeaker delivers a truly mind-blowing performance. The 8-ohm nominal impedance ensures compatibility with a wide range of amplifiers, allowing you to unleash its full potential.
Featuring an impressive sensitivity of 99dB (1w/1m), this speaker ensures crystal-clear sound reproduction even at high volumes. The frequency response of 40Hz-5KHz guarantees a wide range of sound, capturing every detail of your music.
One of the standout features of the DS18 12PRO2500MB-8 is its Interleaved Sandwich Voice Coil (ISV). This innovative design enhances heat dissipation, allowing for prolonged use without compromising on performance. The 4″ voice coil diameter, made from high-quality fiberglass material, ensures optimal power handling and minimal distortion.
This speaker has a curvilinear cone shape, delivering precise and accurate sound reproduction. The non-pressed paper cone material, combined with a cloth surround, provides durability and excellent transient response.
With push terminals featuring spring-loaded connections, installation is a breeze. The aluminum basket not only adds to the speaker’s ruggedness but also improves overall sound dispersion.
DS18’s 12PRO2500MB-8 is a must-have for any professional audio system!
