Pioneer DMH‑W4600NEX/B
The Pioneer DMH‑W4600NEX/B is a high‑feature double‑DIN digital multimedia receiver featuring a 6.8″ capacitive touchscreen and broad smartphone connectivity. It offers wireless and wired Apple CarPlay®, wireless and wired Android Auto™, built‑in WiFi®, Bluetooth®, Amazon Alexa Built‑In, and HD Radio™ + SiriusXM‑Ready support.
Specifications
PRODUCT PERFORMANCE
| Feature | Details |
|---|---|
| Continuous Power Output | 22 W x 4-Channel |
| Load Impedance Allowance | 4 Ohm (4 Ohm to 8 Ohm Allowable) |
| Max Power Output | 50 W x 4-ch 4 ohm, 50 W x 2-ch 4 ohm, 70 W x 1-ch (subwoofer) 2 Ohm |
| RCA Preamp Outputs | 6-ch |
| RCA Preout Voltage | 4V |
| RMS Power Output (CTA-2006) | 14 W RMS x 4-ch 4 ohm |
GENERAL
| Feature | Details |
|---|---|
| Detachable Face Security | Fixed |
| Multi-Language Display | English, French, Spanish, Portuguese, Chinese (Simplified) |
| Music Browser | USB |
| Remote Control | Optional |
| Steering Wheel Control Ready | Yes (Adapter Sold Separately) |
DISPLAY
| Feature | Details |
|---|---|
| Back Light | LED |
| Brightness Control | Yes |
| Color Customization | 5 display colors, 112 key colors |
| Device (Non-DIN/Modular Unit) | 2-DIN, Short Chassis |
| Dimmer | Automatic with vehicle illumination, Timer Controlled, Manual |
| Display Off Mode | Yes |
| Home Screen Customization | Yes |
| Monitor Mechanism | Fixed |
| Resolution | WVGA (800 x 480) |
| Screen Size / Aspect Ratio | 6.8″ / 16:9 |
| Touch Screen | Capacitive |
NAVIGATION
| Feature | Details |
|---|---|
| External GPS Antenna | Yes |
BLUETOOTH
| Feature | Details |
|---|---|
| Advanced Audio Distribution Profile (A2DP) | Yes |
| AVRCP | 1.6 |
| Built-in Bluetooth® | Yes |
| Dual Phone Connection | Yes |
| Hands-Free | True |
| Microphone Included | Included |
| Phone Registration | 5-phone |
| Secure Simple Pairing (SSP) | Yes |
| Serial Port Profile (SPP) | Yes |
TUNER
| Feature | Details |
|---|---|
| Best Station Memory | Yes |
| HD Radio™ | Built-In, Artist Experience, Multicasting |
| Hybrid Radio | Yes |
| Local Seek Tuning | Yes |
| Presets | 18 FM, 6 AM |
| RDS | Yes |
| SiriusXM-Ready™ (Tuner Sold Separately) | Yes |
INTEGRATION
| Feature | Details |
|---|---|
| Amazon Alexa | Built-In |
| Android Auto™ | Wireless or Wired USB Connection |
| Apple® CarPlay | Wireless or Wired USB Connection |
| CarAVassist | Yes |
| Mobile Operating System | Android, Apple iOS |
| Music Playback (MTP) | Yes |
| Pandora® | With Apple CarPlay or Android Auto |
| Pioneer App Compatibility | CarAVAssist Android, CarAVAssist iPhone |
| Siri® Eyes Free (VR) | iPhone Only |
| Spotify | With Apple CarPlay or Android Auto |
| Voice Control | Yes |
| WiFi | Tethering, WiFi Hotspot |
DIGITAL MEDIA PLAYBACK
| Feature | Details |
|---|---|
| Audio Playback via USB | MP3, WMA, WAV (Hi-Res), AAC, FLAC (Hi-Res), DSD (Hi-Res), DivX |
| Audio Video Playback via USB | .avi, .mpg/mpeg, .divx, .mp4, .3gp, .mkv, .flv, .wmv/.asf, .m4v, H.263, H.264, .ts/.m2ts/.mts |
| Image Display via USB | BMP, JPEG, PNG |
AUDIO
| Feature | Details |
|---|---|
| Advanced Sound Retriever | Mode-1/Mode-2/Off |
| Audio Bass Boost | Yes |
| Balance | Yes |
| Built-in Amplifier | MOSFET 50 W x 4 |
| Crossover Network Mode | HPF / Band Pass / LPF |
| Crossover Standard Mode | HPF / LPF |
| Customizable Graphic Equalizer | 13 Band |
| DA Converter | 24 Bit |
| Digital Signal Processor | Built-In |
| Dynamic Bass Enhancer | Off / Low / High |
| Easy EQ (EEQ) Preset Equalizer | Yes |
| Listening Position Selector | Yes |
| Loudness | High / Mid / Low / Off |
| Speaker Output | 4-ch |
| Spectrum Analyzer | True |
| Subwoofer Control | Yes |
| Time Alignment | Manual |
EXPANDABILITY
| Feature | Details |
|---|---|
| Audio Video Inputs | Input 1 – Backup Camera Dedicated, Input 2 – AUX (Minijack) |
| OEM Integration | iDatalink Maestro RR, iDatalink Maestro RR2, Metra Axxess |
| OTA Update Compatible | Yes |
| Parking Assist Lines | Yes |
| RCA Video Output | Yes |
| USB | Rear, Type-C (5 V, 3.0 Amp) |
| USB Direct Control for iPhone® | 5s and newer |
About The Product
This is a Pioneer Reconditioned product, including a 90-day limited warranty.
Our DMH-W4600NEX has the latest connectivity solutions designed especially for today’s smartphone driven lifestyle. This receiver is a Capacitive touchscreen display. Features include built-in Bluetooth® Amazon Alexa Built-in, Android™ Auto, Apple CarPlay®, Satellite Radio (SiriusXM-Ready™) and much more. The DMH-W4600NEX has 13-band graphic equalizer and is equipped a back-up camera input.
Android Auto
This receiver also features Android Auto, which extends the Android platform into the car in a way that’s purpose-built for driving. Android Auto automatically brings you useful information and organizes it into simple cards that appear just when they’re needed. It’s designed to minimize distraction so you can stay focused on the road ahead. Android Auto is compatible with Android phones running Android 5.0 (Lollipop) or later. Android Auto may not be available on all devices.
Back up camera input (1-camera)
Back up safely in any crowded parking area. Install a rear-view camera to use the receiver’s built-in parking guides for easy parking, with adjustable parking lines and full screen image for ease of use.
Apple CarPlay
This receiver features Apple CarPlay, the smarter, safer and more fun way to use your iPhone® in the car. Apple CarPlay gives iPhone users an incredibly intuitive way to make calls, use Maps, listen to music, and verbally send and listen to messages with just a word or a touch. Apple CarPlay requires iPhone 5 device or newer with the latest version of iOS.
Sound quality for all
Your car and your music are as unique as you are. With a receiver, sound quality features like built-in EQ and Time Alignment, 13-Band Graphic Equalizer with touch panel swipe settings and built-in high/low pass crossover with adjustable points and slopes provide you with the controls to tailor the listening experience to your vehicle and listening preferences.
Alexa Built-in
This in-dash receiver features the latest automotive connectivity solutions, including Amazon Alexa Built-in. With Alexa, users can talk to Amazon Alexa directly through this Pioneer receiver. With Alexa, you can ask to play music, hear the news, check the weather, control smart home devices*, and more. Alexa lives in the cloud, so it’s always getting smarter, adding new capabilities that are delivered to compatible devices automatically. Using Alexa with the Pioneer units is simple and hands-free – just ask, and Alexa will respond instantly.
iDataLink Maestro (RR)
Keep your factory features and expand your level of in-vehicle connectivity with Pioneer NEX and iDatalink Maestro RR. When your receiver is installed in a compatible vehicle using the iDatalink Maestro RR interface (sold separately), you will be able to enjoy the performance and features of this receiver plus touchscreen control over key factory audio features. This Receiver supports factory functions via the iDatalink Maestro RR interface including: Steering Wheel Controls, Media Player (including the factory AUX-in and USB ports), Hands-Free Telephone, Voice Commands, Satellite Radio, and Secondary Display Support.
iDataLink Maestro (RR & RR2)
Universal Radio Replacement Interface. The Maestro RR and RR2 connect to iDatalink-compatible radios to enhance your multimedia experience with exclusive gauges, vehicle information, parking assistance, climate control, and radar detection screens. They retain the factory infotainment features you love, such as steering wheel controls, voice commands, and more (sold separately).
Siri® Eyes Free – touchscreen
Simply touch a NEX touchscreen and Siri listens through the NEX unit’s external microphone and answers requests over the vehicle’s speakers, helping you keep your eyes on the road and your hands on the wheel. (For select iPhones.)
Bluetooth
This receiver makes hands-free phone calls simple. Pioneer’s included external microphone provides crystal clear sound. Stream music, podcasts, audiobooks, and more from your compatible phone or other Bluetooth® devices.
FLAC
Your love of high-res audio does not need to stop at the front door. Enjoy FLAC files in your vehicle without the need to convert. Pioneer’s NEX in-dash receivers were the first in the industry to offer playback of files encoded as high-res FLAC up to 192kHz/24 bit and provide playback output at CD quality. With Pioneer, your high-res FLAC is no longer confined to your home hi-fi system – put your music on the move.
Time alignment
This feature allows for delay time and synchronizing from each speaker to be adjusted to correct any phase mismatches in the sound resulting from the listening position. No need for any acoustics degree to do the job, simply measure the distance between your listening position and the speakers, then enter these measurements into the Pioneer receiver.
CarAV Assist
CarAVAssist This in-dash receiver is compatible with the CarAVAssist App, which supports home screen customization and other functions. You can bookmark websites that you want to enjoy in your car while parked, register your favorite sports teams to receive real-time game updates, make notifications settings for your smartphone, and more. The app also allows you to customize your receiver’s home screen, including adding your own background image and easily performing OTA (Over The Air) Firmware Updates.
Wireless connectivity
This Pioneer receiver supports a cable-free connection between your smartphone using built-in WiFi® and built-in Bluetooth® for wireless connectivity. It is compatible with both Android Auto and Apple CarPlay. You have the choice of using it wirelessly or with a wired connection.
WVGA Touchscreen (Capacitive)
Upgrade your ride with a capacitive WVGA touchscreen The Display with built-in LED backlight, color customization, and illumination timer, dimmer setting, and brightness control.
