Pioneer DEH‑S6220BS
The Pioneer DEH‑S6220BS is a single‑DIN CD receiver designed for modern vehicles looking for strong audio features paired with smartphone connectivity. It includes built‑in Bluetooth® for hands‑free calling and wireless music streaming, USB and AUX inputs (with CD playback support), and compatibility with the Pioneer Smart Sync app (which enables voice‑control via Amazon Alexa when paired). On the audio front, it offers three pairs of 4‑volt RCA pre‑outs for front/rear/subwoofer expansion, a built‑in MOSFET amplifier rated up to 50 W × 4 channels (peak), a 13‑band graphic equaliser (expandable to 31 bands via the Smart Sync app), and full DSP features including selectable crossover and time‑alignment.
Specifications
PRODUCT PERFORMANCE
| Feature | Specification |
|---|---|
| Continuous Power Output | 22 W x 4-Channel |
| Load Impedance Allowance | 4 Ohm (4–8 Ohm Allowable) |
| Max Power Output | 50 W x 4-ch 4 ohm, 50 W x 2-ch 4 ohm, 70 W x 1-ch (subwoofer) 2 Ohm |
| RCA Preamp Outputs | 6-ch |
| RCA Preout Voltage | 4V |
| RMS Power Output (CTA-2006) | 14 W RMS x 4-ch 4 ohm |
GENERAL
| Feature | Specification |
|---|---|
| Detachable Face Security | Detachable |
| Multi-Language Display | English, French, Spanish |
| Music Browser | USB, with Smart Sync App |
| Remote Control | Optional |
| Rotary Volume Control | Yes |
| Steering Wheel Control Ready | Yes (Adapter Sold Separately) |
DISPLAY
| Feature | Specification |
|---|---|
| Back Light | LED |
| Brightness Control | Yes |
| Color Customization | 210,000 Colors, dual zone |
| Device Display | VA LCD (2-Line) |
| Device Type | 1-DIN |
| Dimmer | Automatic with vehicle illumination, Timer Controlled, Manual |
NAVIGATION
| Feature | Specification |
|---|---|
| Map Data | N/A |
| Map Provider | N/A |
| Point of Interest | N/A |
BLUETOOTH
| Feature | Specification |
|---|---|
| Advanced Audio Distribution Profile (A2DP) | Yes |
| AVRCP | 1.6 |
| Built-in Bluetooth® | Yes |
| Dual Phone Connection | Yes |
| Hands-Free | Yes |
| Microphone Included | Yes |
| Phone Registration | 5 phones |
| Secure Simple Pairing (SSP) | Yes |
| Serial Port Profile (SPP) | Yes |
| Sound Retriever Air | Mode 1 / Mode 2 / Off |
TUNER
| Feature | Specification |
|---|---|
| Best Station Memory | Yes |
| Local Seek Tuning | Yes |
| Presets | 18 FM, 6 AM |
| RDS | Yes |
| SiriusXM-Ready™ | Yes (Tuner Sold Separately) |
| HD Radio™ | Built-In, Multicasting |
INTEGRATION
| Feature | Specification |
|---|---|
| Amazon Alexa | Paired with Pioneer Smart Sync |
| Mobile Operating System | Android, Apple iOS |
| Music Playback (MTP) | Yes |
| Pandora® | Source via iPhone/Android |
| Pioneer App Compatibility | Pioneer Smart Sync Android, Pioneer Smart Sync iPhone |
| Siri® Eyes Free (VR) | iPhone Only |
| Spotify | Streaming via iPhone/Android through Bluetooth or AUX |
| Voice Control | Yes |
DIGITAL MEDIA PLAYBACK
| Feature | Specification |
|---|---|
| Audio Playback via CD | AAC, MP3, WAV, WMA |
| Audio Playback via USB | MP3, WMA, AAC, FLAC (Hi-Res), WAV (Hi-Res) |
AUDIO
| Feature | Specification |
|---|---|
| Advanced Sound Retriever | Mode-1 / Mode-2 / Off |
| Balance | Yes |
| Built-in Amplifier | MOSFET 50 W x 4 |
| Crossover Network Mode | HPF / Band Pass / LPF |
| Crossover Standard Mode | HPF / LPF |
| Customizable Graphic Equalizer | 13 Band, 31 Band with Pioneer Smart Sync App |
| DA Converter | 24 Bit |
| Digital Signal Processor | Built In |
| Dynamic Bass Enhancer | Off / Low / High |
| Easy EQ (EEQ) Preset Equalizer | Yes |
| Listening Position Selector | Yes |
| Loudness | High / Mid / Low / Off |
| MIXTRAX® | Yes |
| Source Level Adjuster | Yes |
| Speaker Output | 4-ch |
| Spectrum Analyzer | Yes |
| Subwoofer Control | Yes |
| Time Alignment | Manual |
EXPANDABILITY
| Feature | Specification |
|---|---|
| Audio Video Inputs | Input 2 – AUX (Minijack) |
| Firmware Upgradability | Yes |
| USB | Front Type-A (5V, 1.5 A) |
| USB Direct Control for iPhone® | 5s and newer |
About The Product
The DEH-S6220BS Single DIN CD receiver offers smartphone integration, Bluetooth®, SiriusXM, and other audio options. Equipped with Pioneer Smart Sync, this receiver, when paired with your smartphone, brings together navigation apps, messages, music, and more through a clean, intuitive interface. Enjoy your CDs or FLAC files from a USB drive, or stream audio from your phone via Bluetooth®. It features a 13-band customizable graphic equalizer, which increases to 31 bands when using Pioneer Smart Sync. The crossover network operates in either Standard Mode or Network Mode.
CD Player
Play your collection of audio discs with ease. Both burned and original CDs are supported for music playback.
Pioneer Smart Sync
Pioneer Smart Sync is a highly evolved app available for iOS and Android OS that expands the features and interface of compatible Pioneer in-dash receivers. Using either Bluetooth® or USB, the connection can be wired or wireless. You can access popular smartphone apps for maps, messages, music, connect to an OBDII module (sold separately), and more.
Smart Sync now includes Amazon Alexa Built-in. Simply download or update the Pioneer Smart Sync app and the Alexa app. With Alexa, you can ask to play music, check weather, get news, control smart home devices, and more. Alexa continually updates automatically in the cloud.
Smart Sync also acts as a wireless remote control, letting you tune sound and save settings via the app.
Smartphone Control
Directly access music on your smartphone. Search for Artists, Albums, and Songs using the intuitive interface. Control compatible music and radio apps from your phone through the receiver.
Bluetooth
Hands-free calls are easy with the included external microphone. Stream music, podcasts, and audiobooks from your phone or other Bluetooth® devices.
Siri® Eyes Free
Ask Siri to answer questions or send commands through the receiver, keeping your eyes on the road and hands on the wheel.
SiriusXM Ready
Over 140 channels including music, sports, news, and talk. Compatible with SiriusXM Connect Vehicle Tuner (SXV300 sold separately; subscription required).
USB Auto Switch
Choose whether the connected phone functions as a source or charges only when plugged in via USB.
Wired Remote Input
Connect a third-party interface (optional) to retain steering wheel control functions.
Pioneer Advanced Sound Retriever
Enhances detail, warmth, and clarity from compressed audio files, counteracting compression effects for a natural sound.
Flexible Audio Output Management
Divide audio into different frequency bands for precise adjustments with low-pass, high-pass, and band-pass filters, level, and phase. Select STD for Sub/Rear/Front or NTW for Low/Mid/High speaker setups.
Audio Equalizer
13-band equalizer allows detailed tuning to match car interior acoustics. Multiple EQ presets make it easy to customize even for beginners.
Time Alignment
Correct phase mismatches by adjusting speaker delay times according to listening position.
MIXTRAX
Creates a continuous mix of your music library with DJ-inspired effects. Supports iPhone, iPod, USB, and select Android devices. Club-style illumination pulses to the beat of the music, with multiple lighting pattern options via sound pressure level or low-pass sync modes.
