Description
Infinity BassLink Mini
The Infinity BassLink MINI is a compact under-seat powered subwoofer system designed to deliver deep, punchy bass without taking up much space in your vehicle. It features a 6″×8″ shallow-profile subwoofer paired with a built-in 100W RMS amplifier (200W peak), providing tight and accurate low-frequency performance. Housed in a durable die-cast aluminum enclosure, it minimizes vibration and heat while maintaining a slim design ideal for hidden installation. The system includes adjustable controls such as low-pass crossover (50–150Hz), bass boost (0 to +12dB), and a wired remote bass control, allowing you to fine-tune your sound easily. With a frequency response of 30Hz – 150Hz, the BassLink MINI is perfect for upgrading factory audio systems with powerful bass while maintaining space efficiency.
Specifications
| General Specifications | Details |
|---|---|
| Driver Complement | 6″x8″ (152mm x 203mm) Subwoofer |
| Amplifier Power | 100W RMS; 200W Max |
| Frequency Response | 30Hz – 150Hz |
| Fuse | 15A |
| Maximum Current Draw | 13 A |
| Quiescent Current Draw | <600 mA |
| Input Sensitivity | 0.1V – 4.0V (Low-Level); 0.25V – 20V (High-Level) |
| Crossover Frequency | 50Hz – 150Hz |
| Crossover Slope | 12 dB/octave |
| Bass Boost | 0dB to +12dB @ 50Hz |
| Dimensions (L x W x H) | 11-7/16″ x 8-5/16″ x 3″ (289.6mm x 209.6mm x 75.0mm) |
| Weight | 8.22 lbs (3.73 kg) |
About The Product
Infinity BassLink MINI delivers deep bass and takes up little space. Infinity’s smallest powered subwoofer can be hid in the most compact of locations and deliver exceptional performance to any car audio system. Powered by a 100Watts Amplifier, Basslink MINI delivers accurate, tight bass you would expect from Infinity, all while running cool and drawing minimal current from your vehicles charging system.
